Impulse EL630-NR - Manual (Page 2)

DFI reserves the right to change the specifi cations at any time prior to the product's release. Changes thereafter will be based on the product's revision.
Please contact your sales representative for the exact revision offered in your area. All product names mentioned are trademarks of their respective
companies. © December 28, 2012 DFI Inc.
www.dfi .com
• USB port cable
• COM port cable
• Serial ATA data cable
• Serial ATA power cable
• I/O shield
• IDE cable
Specifi cations
EL630-NR
ATX
PROCESSOR
• LGA 775 socket for:
- Intel
® Core TM 2 Quad Q9400
- Intel ® Core TM 2 Duo E8400/E7400/E6400/E4300
- Intel ® Pentium ® E6500/E5300/E2160
- Intel ® Celeron ® E3400/E1500/440
• Supports Intel ® Enhanced Memory 64 Technology (EMT64T)
• Supports Enhanced Intel SpeedStep Technology (EIST)
• 1333/1066/800MHz FSB
CHIPSET
• Intel
® chipset
- Intel ® Q45 Express chipset
- Intel ® ICH10DO I/O Controller Hub
SYSTEM MEMORY
• Four 240-pin DDR3 DIMM sockets
• Supports DDR3 800/1066MHz DIMM
• Maximum memory bandwidth of 17GB/s in dual channel
mode when using DDR3 1066MHz
• Supports dual channel memory interface
• Supports up to 8GB system memory
• Supports unbuffered x8 and x16 DIMMs
EXPANSION SLOTS
• 1 PCI Express x16 slot (PCIE 2.0)
• 1 PCI Express x4 slot (PCIE 1.1)
• 5 PCI slots (PCI 2.3)
ONBOARD GRAPHICS FEATURES
• Integrated Intel GMA 4500
- Supports 3D, 2D and video capabilities, DX10 and OpenGL 2.1
• Display ports: DVI-I (Chrontel CH7307C) and VGA
ONBOARD AUDIO FEATURES
• Realtek ALC262 2-channel High Defi nition Audio
• Two 24-bit stereo DACs and three 20-bit stereo ADCs
• S/PDIF audio interface
ONBOARD LAN FEATURES
• Two Realtek RTL8111C PCI Express Gigabit Ethernet controllers
• Supports 10Mbps, 100Mbps and 1Gbps data transmission
• IEEE 802.3 (10/100Mbps) and IEEE 802.3ab (1Gbps) compliant
SERIAL ATA (SATA) INTERFACE
• 6 SATA (Serial ATA) interfaces compliant with SATA 1.0 specifi cation
• SATA speed up to 3Gb/s (SATA 2.0)
• Supports RAID 0/1/5/10
IDE INTERFACE
• Supports up to two IDE devices
• Supports Ultra ATA 133/100/66/33
BIOS
• Award BIOS
- 8Mbit SPI BIOS
REAR PANEL I/O PORTS
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• 2 DB-9 RS232 serial ports
• 1 DVI-I port (DVI-D signal)
• 1 DB-15 VGA port
• 2 RJ45 LAN ports
• 4 USB 2.0/1.1 ports
• Mic-in, line-in and line-out
I/O CONNECTORS
• 4 connectors for 8 external USB 2.0/1.1 ports
• 2 connectors for 2 external RS232 serial ports
• 1 8-bit DIO connector
• 1 front audio connector for line-out and mic-in jacks
• 1 CD-in connector
• 1 S/PDIF connector
• 6 Serial ATA connectors
• 1 40-pin IDE connector
• 1 FDD connector
• 1 24-pin ATX power connector
• 1 4-pin 12V power connector
• 1 chassis intrusion connector
• 1 front panel connector
• 3 fan connectors
ENERGY EFFICIENT DESIGN
• ACPI v3.0b specifi cation
• System Power Management
• Wake-On-Events include:
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
- Wake-On-Ring
- RTC timer to power-on the system
• AC power failure recovery
DAMAGE FREE INTELLIGENCE
• Monitors CPU/system temperature and overheat alarm
• Monitors CPU/DIMM/3.3V/5V/12V/Chipset Vcore/VBAT voltages and
failure alarm
• Monitors CPU/system/2nd fan speed and failure alarm
• Read back capability that displays temperature, voltage and fan
speed
• Watchdog timer function
POWER CONSUMPTION
• 120.22 W with Intel ® Core TM 2 Quad Q9400 at 2.66GHz and 2x 1GB
DDR3 DIMM
TEMPERATURE
• 0 o C to 60 o C
HUMIDITY
• 10% to 90%
DIMENSIONS
• ATX form factor
• 305mm (12") x 244mm (9.6")
CERTIFICATION
• CE
• FCC Class B
• UL
• RoHS
• 1 EL630-NR motherboard
• 1 IDE cable
• 2 USB cables
• 2 Serial ATA data cables
• 2 Serial ATA power cables
• 1 COM port mounted on a bracket (2 pcs)
• 1 I/O shield
• 1 CD
• 1 QR (Quick Reference)
Packing List Optional Items
