Impulse GENE-5315 Rev. A - Manual (Page 2)

03-30
Dimension
Unit: mm
GENE-5315 Rev. A
Optional Accessories
1702200205 •
Conversion Cable for ATX Power Supply, Length 20cm
1709140181 •
Audio Cable, Length 18cm
1709100208 •
USB Cable, Length 20cm
1701100206 •
COM Port Cable, 9P DB Male, Length 20cm
1701260201 •
Parallel Port Cable, Length 20 cm
1701340600 •
Floppy Cable, Length 60 cm
Part Number CPU
Fan/
Fanless
Display LVDS Storage LAN USB RS-232 RS-232/422/485 Expansion Slot Power Temp
TF-GENE-5315-A11 AMD Geode™ LX800 Fanless
CRT + LVDS
CRT + TTL
24-bit, 1CH
EIDE x 1
Floppy x 1
CompactFlash™ x 1
FE x 2 4 1 1
Mini PCI x 1
PC/104 x 1
+5V DC 0°C ~ 60°C
TF-GENE-5315-A11-01 AMD Geode™ LX800 Fanless
CRT + LVDS
CRT + TTL
18b, 1CH
EIDE x 1
Floppy x 1
CompactFlash™ x 1
FE x 2 4 1 1
Mini PCI x 1
PC/104 x 1
+5V DC 0°C ~ 60°C
Ordering Information
