01-8
Dimension
Unit: mm
Optional Accessories
Ordering Information
Part Number CPU Fan/ Fanless Display LVDS Storage LAN USB RS-232 RS-232/422/485 Expansion Slot Power Temp
TF-PCM-8120-A10-04 VIA Eden™ 1G ULV Fanless
CRT + LVDS
CRT + TTL
24b, 2CH
SATA x 2
IDE x 1
CompactFlash™ x 1
FE x 2 6 3 1
Mini PCI x 1
PCI x 1
PC/104 x 1
ATX 0°C ~ 60°C
TF-PCM-8120-A10-05 VIA Eden™ 1G ULV Fanless
CRT + LVDS
CRT + TTL
24b, 2CH
SATA x 2
IDE x 1
CompactFlash™ x 1
FE x 2 6 3 1
Mini PCI x 1
PCI x 1
PC/104 x 1
PCMCIA x 1
ATX 0°C ~ 60°C
TF-PER-A031 •
Cable Kit for PCM-8120
1700300240 •
DVI Cable
TF-PER-C10L-A10 •
Mini PCI 10/100Base-TX Ethernet Module with Realtek 8100C
TF-PER-C10L-A10-01 •
Mini PCI 10/100/1000Base-TX Ethernet Module with Realtek 8110S
TF-PER-C10L-A10-03 •
Mini PCI 10/100/1000Base-TX Ethernet Module with Intel® 82541GI
TF-PER-C30F-A10 •
Mini PCI 3-port IEEE 1394a Module
TF-PER-C40C-B10 •
Mini PCI 2-port RS-232 Module Rev. B1.0
TF-PER-C40C-B10-01 •
Mini PCI 4-port RS-232 Module Rev. B1.0
127.89
PCM-8120
