Page 2: Ordering information
02-8
Dimension
Unit: mm
1700290150
•
DVI-I to DVI + VGA Cable, Length 15cm
1700060157
•
KB/Mouse Cable
TF-PER-C41C-A10
•
4 COM Ports Mini Card
Optional Accessories
EPIC-QM57
Ordering Information
Part Number
CPU
Fan/Fanless
Display
LVDS
Storage
LAN
USB
RS-232
RS-232/422/485
Expansion Slot
Power
Temp
EPIC-QM57-A11
Socket-988
FAN
DVI+LVDS
24-bit, 2CH
SATA x 2
CompactFlash™ x 1
GbE x 2
6
3
1
PCI/104-Express x 1
Mini Card x 1
+12V, AT/ATX
0°C ~ 60°C
