02-2
Dimension
Unit: mm
EPIC-QM77
Ordering Information
Part Number CPU Fan/Fanless Display Combination Storage LVDS LAN USB RS-232 RS-232/422/485 Expansion Slot Power Temp
TBD i7-3555LE Fanless
CRT + DVI,
LVDS x 2, HDMI SATA x 2
mSATA x 1
24-bit, 2CH 2
USB3.0 x 2,
USB2.0 x 6
5 1
PCI-104 x 1
Mini Card x 1, the 2nd Mini
Card (Optional)
+12V, AT/ATX 0°C ~ 60°C
TBD i5-3517UE Fanless
CRT + DVI,
LVDS x 2, HDMI SATA x 2
mSATA x 1
24-bit, 2CH 2
USB3.0 x 2,
USB2.0 x 6
5 1
PCI-104 x 1
Mini Card x 1, the 2nd Mini
Card (Optional)
+12V, AT/ATX 0°C ~ 60°C
TBD •
Optional Accessories
Launching in Q2
