Controlled Products Systems Group SPX-7500 User Manual
Page 16
*
8 to 16 VDC In
Ground
RLY2 N.O.
RLY2 Com
RLY2 N.C.
RLY1 N.O.
RLY1 Com
RLY1 N.C.
RS232 Out
RS232 In
Ground
Aux In
N/C
N/C
485(+)
485(-)
+5 VDC Out
RLY4 Input (5V)
RLY3 Input (5V)
LED Output
D1 Input
D0 Input
Door
Strike
Output
Ground
+8 to +16 VDC
D0/Clock In
D1/Data In
LED Out
485(-)
485(+)
R1 N.C.
R1 Com
R1 N.O.
Card
Reader
DC
Power
Supply
Cypress Suprex Series - Wiegand Expansion Module
Reader/Door “Remote” interface
EXP-2000
Remote Unit
