Controlled Products Systems Group SPX-5601 User Manual

Page 2

This manual covers the operation and setup of the Cypress Suprex RF SPX-5000 series wireless units.

Overview

The SPX-5000 series of RF Wireless solutions provides a wireless bridge from Card Readers with gates or door
hardware to most access control manufacturers panels. The SPX or Suprex® products include both the remote
( Door/Gate ) unit and the central ( AC Panel ) unit. In the case of the SPX-5000 series of wireless products optional
repeaters / extenders are also available.

Features:

-- Includes complete solution with remote ( reader/gate/door ) and central ( panel ) interface.
-- Service mode for setup and configuration.
--“Quiet” protocol to conserve bandwidth and power
-- Field configurable reader formats
-- Multifunction indicator for determining operational status of the unit
-- Auxiliary I/O connections available for Door/Gate/Panel status signaling.
-- Multiplexing of RF bridge providing for additional door/gate on a single RF link.
-- Economical expansion capabilities using Suprex Lynk technology

RF Specifications:

2.4GHz or 900Mhz frequency
AES Encryption upon request

Cypress Suprex SPX-5000 Series Overview

Electrical and Mechanical Specifications

Cypress Computer Systems, Inc.

⌖ Lapeer, MI 48446 ⌖

www.cypresscomputer.com

Physical

SPX-5XXX - Weatherproof Enclosure - ABS - IP65
6.75” x 4.75” x 2.10” (Each unit)

Temp

Storage(-55˚C to + 150˚C) - Operating(-40˚C to +80˚C)

Humidity

95% (non-condensing)

Power

Input

Unreg Input 8 to 16 VDC* @ 500mA Max

Power

Output

+5VDC @100mA

Data I/O

Interface

Reader -Wiegand, Strobed (Clock & Data), F/2F
LED - 0 - 30V

Relays

Max Switching

(220Vdc 30W (resistive) 1A)

Relays

Max Switching

(250Vac 37.5VA 1A)

Relays

Running Spec with load

(30Vdc 1A (resistive), 1 x 10

operations at 20

Relays

Running Spec with load

125Vac .3A (resistive), 1 x 10

operations at 20
