RAM 3000 • 3100 • 3200
RAMSET
www.ramsetinc.com 5
RAM 3000 • RAM 3100 • RAM 3200
G e n e r a l S p e c i f i c a t i o n S :
mOdEL: rAm 3000 rAm 3100 rAm 3200
max. gate Length: 22 feet 22 feet 22 feet
max. gate weight: 800 lbs. 1200 lbs. 1200 lbs.
Cycles: Continuous Continuous Continuous
Aerovox 65µƒ, 240 V, 50/60 Aerovox 65µƒ, 240 V, 50/60 Aerovox 65µƒ, 240 V, 50/60
Capacitor: HZ, protected S 1000AFC HZ, protected S 1000AFC HZ, protected S 1000AFC
Application: Commercial Commercial Com./Industrial
Finish and Gold/Zinc plated Gold/Zinc plated Gold/Zinc plated
Construction: 1/4” H.R. Metal 1/4” H.R. Metal 1/4” H.R. Metal
Continuous duty 1/2 Hp 120 Vots. AC 3/4 Hp 120 Vots. AC 1 Hp 220 Vots. AC
motor: 4.5 amp. 1625 rpm. 8.5 amp. 1625 rpm. 4.5 amp. 1625 rpm.
power Failure *By hand lever release or *By hand lever release or *By hand lever release or
release: optional battery Back-up system. optional battery Back-up system. optional battery Back-up system.
Overall dimensions: H: 28 1/2” - L: 23” - W: 18” H: 28 1/2” - L: 23” - W: 18” H: 28 1/2” - L: 23” - W: 18”
gate Travel Speed: Approx. 90°opening in 20 sec. Approx. 90°opening in 20 sec. Approx. 90°opening in 20 sec.
Shipping weight: 135 lbs. 150 lbs. 150 lbs.
Emergency Release:
*By Release Lever; remove cap, lift up
release handle and push gate open.
• OPTIONAL BBS. (1000 LBS MAx)
• OPTIONAL POWER INVERTER.
(1/2 & 3/4 HP UNITS ONLY)
wArNiNg
Do not exceed the specifications.
