Manual 2100-518B

Page

9 of 30

1/4" TAPCON SCREWS

MIS-2660

1/4" LAG BOLTS

DIRECTLY INTO STUD

fiGure 4

mOuntinG

FIGURE 4A

Studded Wall Mounting

FIGURE 4B

Masonry Wall Mounting
