AMABILIA DOUBLE O-RING GEOTHERMAL FLOW CENTERS DORFC-2 User Manual
Page 25
Manual 2100-518B
Page
25 of 30
10
120
110
100
90
80
70
60
50
40
30
20
0
Retaining cap, hand tighten only
Pete's test plug
Test plug cap
Barbed 90° adapter
MIS-2622 A
NOTE: Slide retaining cap back to expose
double o-rings. Apply petroleum jelly to o-rings
to prevent damage and aid in insertion
with guage adaptor
Dial face pressure guage
Thermometer
model
GPm
GV27s1
GV38s1 / GV51s1
GV61s1
GV71s1
Psid
ft. hd.
Psid
ft. hd.
Psid
ft. hd.
Psid
ft. hd.
3
0.1
0.23
4
0.5
1.15
0.9
2.08
5
1.2
2.77
1.4
3.23
6
1.7
3.92
2.3
5.31
7
2.3
5.31
3.2
7.38
2
4.61
8
3.1
7.15
4.1
9.46
2.5
5.77
2
4.61
9
4.1
9.46
5.1
11.77
3.2
7.38
2.4
5.54
10
6.1
14.07
3.9
9.00
2.8
6.46
11
7.1
16.38
4.7
10.84
3.4
7.84
12
8.2
18.92
5.5
12.69
3.9
9.00
13
9.4
21.69
6.4
14.76
4.5
10.38
14
10.6
24.45
7.3
16.84
5.2
12.00
15
8.1
18.69
5.9
13.61
16
9
20.76
6.7
15.46
17
9.9
22.84
7.4
17.07
18
8.4
19.38
fiGure 10
Pressure temPerature POrts
table 3a
GV series cOil Pressure drOP
P/T
