(ENTER) (THRU) (THRU) (Input No. 2)
Radio Key ® RK-65K Operating Guide
Secura Key 19
For example, to program the input for LED control, the following
sequence would be followed:
+ + 2 +
BASIC OPERATION (RK65K/RK100M)
To use a Key Tag with Radio Key ® RK-65K, simply hold your
Radio Key ® Transponder near the Radio Key ® RK-65K Unit.
The Radio Key ® RK-65K Unit generates an RF fi eld, which
causes the Key Tag to transmit a unique Transponder ID
Number back to the Unit.
If the Transponder ID Number is stored in memory, the latch
relay is activated, unlocking the controlled door or gate . A
green light and a beep indicates that access is granted. If the
Transponder ID Number is not stored in memory, the door or
gate remains locked and a red light and beep indicate that
access is denied. Otherwise the LED is normally off.
