Programming

Program the Master Code:

The master code is the four-digit number required to gain access to the

receiver memory for all programming. You MUST program a MASTER CODE first.

120 Glasgow Avenue

Inglewood, California 90301

U.S.A.

1st Digit 2nd Digit 3rd Digit 4th Digit

Write Down Your Master Code

?

?

?

?

any four numbers

then press

“BEEP”

2. Choose and enter four-digits on the keypad

1. Press Master Code Button

Important Note:

Keep this instruction sheet for future reference after writing down the master

code . There is NO way of retrieving the master code after it has been programmed in. If you
forget it, you will have to program in a new master code but all other previously programmed
information will remain intact.

Facility Codes:

Unique code for transmitter and located on back of transmitter (Fc).

1. Press and the four-digit Master Code.

2. Press for the FIRST facility code.

3. Enter the two-digit facility code (01-10), then press

4. Repeat steps 2 and 3 to enter additional facility codes.

5. Press TOGETHER to end programming.

1

4

“BEEP”

“BEEP”

“BEEP”

“BEEEEEEEEEP”

1

0

Note: Be sure to increment this number each time another facility code
is entered - up to 10, use 0 for facility code 10 if required.

Transmitter Button Number:

Used to identify the individual transmitter button that will activate the receiver (Up to 3 buttons).

1. Press and the four-digit Master Code.

3. Enter the button number that the receiver is to respond to (1-2-3), then press

5. Press TOGETHER to end programming.

3

2

“BEEP”

“BEEP”

“BEEEEEEEEEP”

0

Relay Strike Time:

The amount of time the receiver relay activates.

1. Press and the four-digit Master Code.

2. Enter a two-digit number (00-99) for the relay activation in seconds, then press

3. Press TOGETHER to end programming.

0

3

“BEEP”

“BEEP”

“BEEEEEEEEEP”

0

Note: 00 programs the relay for 1/2 second.

01 programs the relay for 1 second etc.

Note: Receivers manufactured before Rev E (2/01) require
the receiver case to be opened to access the master code
button. All other programming steps remain the same for
the receivers.

8

7

0

*

9

#

2

1

3

5

4

6

Master Code Button

1 2

3 4

5 6

7 8

Keypad
