Network Combiner NCB/EM
Connectivity for International Telephone Lines – External Modem
Specifications subject to change without notice.
NCB, NCB-EM, NCB-International and WON are trademarks of CTI Products, Inc.
Echelon, LON, LNS, L
ON T ALK , L ON W ORKS , and Neuron
are U.S. Registered trademarks of Echelon Corporation NCB-EM6
NCB/EM™ Specifications: “ International ”
Power (NCB unit only) 10 to 32 VDC, Negative Ground, Externally Current Limited
5 watts max. without SMX transceiver
10 watts max. with SMX PowerLine transceiver
North American and International Power Supplies available.
Power (Modem): Dial-Up : 9 VDC 300 mA
Dial-Up / Leased-Line Optional Modem : 14 VAC 10 VA
Country-specific AC adapter included.
Size: 7.5" D x 5.6" W x 1.6" H
Mounting: Desktop with integral non-slip feet
Wall mount or 19" rack mount with optional adapters
Temperature: 0-60

C
Humidity: 10-95% non-condensing
Listings: UL1459, CSA C22.2, EC EN60950
EMI: Complies with: FCC part 15 Class B,
EN55022 ,Class B (European Union)
EMC: Complies with EN50082-1 (European Union)
European: Carries the CE Mark
Modem: Supports up to 2 external modems. Modems available with
certification in virtually every country world wide.
Transceivers Supported: FTT-10A, TPT/XF-78, TPT/XF-1250, SMX, RS485, PLT22
Serial Data Rate: 1200 bps to 57.6 Kbps
Configuration: Router set as a repeater by factory default. Bridge, Configured,
or Learning type set using standard L ON W ORKS network
management tools capable of configuring routers. LNS plug-in
provided for configuration of telephone parameters.
Installation: Can be done with Standard Network Tools
