Specifications, Inputs & outputs, Physical – CTI Products OTAL On-the Air Terminal Board and Lamp User Manual
Page 9: Pecifications
CTI Products, Inc.
OTAL Terminal Board User Guide
S
PECIFICATIONS
Inputs & Outputs
Power In:
12 to 24 VDC (nominal)
1A
maximum
DC Connector: 5.5 mm barrel x 2.5 mm center pin, center positive
Lamp Drive Out
12 to 24 VDC (nominal – depending on power input) at 1A maximum
Control In:
Dry Closure or Open Collector/Drain
Voltage level dependent upon power supply to board (12-24 VDC Nominal)
10
mA
maximum
Physical
Size:
4.8" x 2.8" x 1.4" (L x W x D)
Terminal
Board
9
