GPIO-CVT Logic Converter Module
GPIO-CVT 2008-04
MCN, and GPIO are trademarks of CTI Products, Inc.. Other trademarks referenced are properties of their respective owners.
Specifications subject to change or improvement without notice.
General Specifications
Size (MCN Size A) 5.5" x 4.2" x 1.5"
(140 x 107 x 38 mm)
Weight 24 oz
Temperature 0-50 o C
Humidity 10- 95% non-condensing
Inputs Optically Isolated
12 – 48 VDC (60 VDC Max)
8 mA max at 48 V input
Logic, Switch Selectable Straight through or Inverted. Applies to all circuits
Custom logic available, contact factory for quotation.
Outputs
Solid State Relays Optically Isolated SPST (Form A)
60 VDC, 500 mA Max.
Active: 2 Ohm Max
Inactive: 2 uA max leakage
Indicators: Power
12 Input LEDs
12 Output LEDs
Equipment Connector 50 pin Telco style, Female
Network Connectors (2) RJ-45 (1 in, 1 out)
Used to pass power to downstream module
Network Cabling 4 Pair Level 4 UTP
Power Input +12 to +30 VDC / 4 W
Models
Part
Number
Model Opto-
Isolated
Inputs
SSR
Outputs
(Form A)
Logic
S2-61418 GPIO-1212-CVT 12 12 Straight Through or Invert
Accessories
Part
Number
Model
S2-60435 MCN Quad 19" Rack Mount Kit (Mounts 4 size A modules) 1 RU high
81-10398 MCN Power Supply 115 VAC
S2-61419 MCN Power Supply, -48VDC to +24 VDC (MCN "A" size module)
S2-61420 Manual, GPIO1212-CVT
S2-61421 Manual, MCN 48VDC Power Supply
