6 JLA Limited 113372-7
MAXIMUM CAPACITY (DRY WEIGHT) 75 lb 34.0 kg
TUMBLER DIAMETER 37” 94 cm
TUMBLER DEPTH 36” 91.5 cm
TUMBLER VOLUME 22.4 cu ft 634.30 L
TUMBLER/DRIVE MOTOR 1 hp * 0.75 kW
BLOWER/FAN MOTOR N / A
DOOR OPENING (DIAMETER) 21-1/2” 54.6 cm
DOOR SILL HEIGHT N / A
WATER CONNECTION 3/4”-11.5 NH (North A merica)
3/4” B.S.P.T. (Outsi de North A merica)
DRYERS PER 20’/40’ CONTAINER 10 / 20
DRYERS PER 48’/53’ TRUCK 24 / 26
VOLTAGE AVAILABLE 120-480V 1,3ø 2,3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 741 lb 336.1 kg
APPROXIMATE SHIPPING WEIGHT 793 lb 359.7 kg
AIRFLOW 60 Hz 1,000 cfm 28.32 cmm
50 Hz 840 cfm 23.78 cmm
HEAT INPUT 175,000 B tu/hr 44,100 kcal/hr
EXHAUST CONNECTION (DIAMETER) 8” 20.32 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
INLET PIPE CONNECTION 3/4” M.B.S.P.T.
3/4” B.S.P.T. (C E and A ustralia Only)
VOLTAGE AVAILABLE
N / A
APPROXIMATE NET WEIGHT
APPROXIMATE SHIPPING WEIGHT
AIRFLOW 60 Hz
50 Hz
EXHAUST CONNECTION (DIAMETER)
COMPRESSED AIR CONNECTION
COMPRESSED AIR VOLUME
OVEN SIZE
kW Btu/hr kcal/hr
30 102,387 25,802
VOLTAGE AVAILABLE 120-480V 1,3ø 2,3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 836 lb 379.2 kg
APPROXIMATE SHIPPING WEIGHT 888 lb 402.8 kg
AIRFLOW 60 Hz 1,000 cfm 28.32 cmm
50 Hz 840 cfm 23.78 cmm
STEAM CONSUMPTION 239 lb/hr 108 kg/hr
OPERATING STEAM PRESSURE 125 psi max 8.6 b ar
EXHAUST CONNECTION (DIAMETER) 8” 20.32 cm
COMPRESSED AIR CONNECTION 1/8” F.N.P.T.
COMPRESSED AIR VOLUME 0.75 cfh 0.02 cmh
BOILER HORSEPOWER (NORMAL LOAD) 7 Bhp
SUPPLY CONNECTION 1” F.N.P.T.
RETURN CONNECTION 1” F.N.P.T.
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
Steam
Gas
Electric
Shaded areas are stated in metric equivalents 4/15/04
* ALL reversing dryers are supplied with two (2) 3-phase (3ø) motors standard: a 1 hp (0.75 kW) blower
motor and a 1/2 hp (0.37 kW) drive motor.
NOTE: The manufacturer reserves the right to make changes in specifications at any time without
notice or obligation.
