6 Technical Specifications
Table 5 includes the technical specifications:
Table 5: Technical Specifications
1
of the High Resolution XGA DA
INPUT:
CDA-VP200N
/ CDA-VGA31
/ CDA-VGA41: 1 analog red, green, blue
signals - 0.7 Vpp/75 , H & V sync, TTL level, on an HD15F connector
OUTPUTS:
CDA-VP200N: 2 analog red, green, blue signals - 0.7 Vpp/75 , H & V sync,
TTL level, on HD15F connectors
CDA-VGA31: 3 analog red, green, blue signals - 0.7 Vpp/75 , H & V sync,
TTL level, on HD15F connectors
CDA-VGA41: 4 analog red, green, blue signals - 0.7 Vpp/75 , H & V sync,
TTL level, on HD15F connectors
MAX. OUTPUT LEVEL: 1.8 Vpp
BANDWIDTH (-3dB):
>400 MHz
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.07 Deg.
K-FACTOR:
<0.05%
S/N RATIO:
72dB
CONTROLS:
Pair of switches for Hs (Horizontal Sync) and Vs (Vertical Sync) on the
underside; ID Bit switch on the underside
COUPLING:
DC
POWER SOURCE:
12 VDC, 95mA
DIMENSIONS:
12cm x 6.95cm x 2.5cm (4.7" x 2.72" x 0.98"), W, D, H
WEIGHT:
0.3 kg. (0.67 lbs.) approx.
ACCESSORIES:
Power supply, mounting bracket
1 Specifications are subject to change without notice
