1 I
MPORTANT
I
NFORMATION
1.1 O
RDER
N
UMBERS
There are two kits available depending on whether there is one transducer like the CLT type or two transducers in
the system.
The MO-13904-1 Barrier Block kit is for one transducer systems.
The MO-13904-2 Barrier Block kit is for two transducers systems.
1.2 C
ONTACT
I
NFORMATION AND
S
ERVICE
A
SSISTANCE
For service assistance, have the following information available:
• Type of Transducer you are using
• Barrier Block Part number
• Purchase order number
You can contact Cleveland Motion Controls at:
Phone:
216.524.8800
Fax:
216.642.5155
For the latest product information, technical literature etc., visit our website at
www.cmccontrols.com
Disassembly by improperly trained personnel may result in additional damage to these units. Should repairs
be required or for warranty repairs, contact the Customer Service Department for a return authorization
number before returning the units.
1.3 R
ECEIVING AND
U
NPACKING
After receiving the Barrier Block Kit you should:
• Carefully, unpack and inspect the equipment
• Compare the received shipment with the packing list
• Report any damage to the carrier and your CMC representative
• Store equipment that will not be used in a clean, dry location
• Take appropriate precautions to prevent moisture, dust and dirt from accumulating in storage and
installation areas
1.4 E
XCITATION
V
OLTAGE
Maximum Excitation Voltage for the Classic Series transducers when used with these Barrier Blocks must be limited
to 5.6 VDC or 5.6 VRMS. Do not use 10 Volt excitation or possible damage to the semiconductor strain gage
elements can occur. Before applying power to the amplifier, verify that the amplifier excitation voltage has been set to
5.0 VDC.
