Cleveland Motion Controls Clutch EMAG 9H - Manual

Nominal torque 12 N.m
ft.lbf 9
Minimal torque 0.14 N.m
ft.lbf 0.1
Coil resistance - 20°C W
23
Rated current DC
A 0.55
Rotor inertia 0.25.10 -3 kg.m 2 lb.ft 2 5.8 10 -3
Weight 4.6 kg
lb 10.15
Heat dissipation
W * 130 550 900
continuous sustained
d epending on external
part rotation speed
(RPM) 0 1000 2000
Specifications
* Heat dissipation is the mechanical power (P = cw) maximum allowable.
Application Notes
• Mounting must be made without any stress.
Lubricated for life (other internal lubrication not allowed).
The shaft should be lubricated upon assembly, to prevent seizing.
• Low DC current power supply for coil.
• The standard device is designed for horizontal shaft orientation,
and a minimal speed of 60 RPM. Maximum speed is 2000 RPM
(without exceeding the max. heat dissipation capability).
• For Engineering application, please contact our technical support.
• In normal use, the outside temperature of the device can increase up to 100°C,
without damage.
Clutch
EMAG 9H
48
55
3,5
3
8
h
5
5
Ш
5,
4
1
1
Ш
8
9
1
Ш
61
9
2
+0,1
0
3
1
J
2,
6
1
4 E9
Ø 15 H7
46
+ 0,3
- 0
7
30
Max. deepness 12
3
0
1
Ø
n
o
°
0
6 t
a
5
M
s
el
o
h
6
2 holes
Ø 4,1
0 0,1 0,2 0,3 0,4 0,5 0,6 0,7 0,8
0
2
4
6
8
10
12
14
m
N
e
u
qr
o
T
Current A
