Cleveland Motion Controls Brake EMAG 4 - Manual

Nominal torque 5 N.m
ft.lbf 4
Minimal torque 0,1 N.m
ft.lbf 0.07
Rated current DC
A 0.50
Rotor inertia 99.10 -6 kg.m 2 lb.ft 2 23 10 -4
Weight 1.7 kg
lb 3.75
Heat dissipation
W *
continuous sustained
70
0 0,1 0,2 0,3 0,4 0,5
0
1
3
4
5
2
Specifications
34
49
7
2
Ø
8
h
0
7
Ш
3
9
Ш
3
5
Ш
2
5 E9
Ø 17 H8
3
1
J
3,
9
1
39,5 + 0,1
- 0
* Heat dissipation is the mechanical power (P = cw) maximum allowable.
Utilization
• Mounting must be made without any stress.
Lubricated for life (other internal lubrication not allowed).
The shaft should be lubricated upon assembly, to prevent seizing.
• Low DC current power supply for coil.
• The standard device is designed for horizontal shaft orientation,
and a minimal speed of 60 RPM. Maximum speed is 3000 RPM.
(without exceeding the max. heat dissipation capability)
• For Engineering application, please contact our technical support.
• In normal use, the outside temperature of the device can increase up to 100°C,
without damage.
Brake
EMAG 4
0
4
x
3
M
s
w
er
c
s
3
0
6
Ø
n
o
°
0
2
1 t
a
m
N
e
u
qr
o
T
Current A
Coil resistance - 20°C
Ohm 24
