AO-70171
14
Revision BA
WebPro Winder Tension Controller
Language
(English, Deutsch, Français, Italiano, Español)
The default language is English. If changed, all text shown on the Controller will be changed to
that language and an extra item "5 - Translations" will be added to the Introduction screen.
Unit system
(SI (newtons), Kgf, pounds/foot, percent)
Select a unit system. All items, which use units, will be changed accordingly.
Winder type
(Speed, Torque, Surface, Clutch)
Select the winder type. In Torque and Speed Control modes tachos or encoders must be
available for line speed and winder (reel) speed signals in order to calculate the reel diameter.
Output range
(0-10V / 0-20mA / 4-20mA / 0-50mA or +/- 2V / +/-10V)
The 0-10V has a maximum output of 10mA and the 0V common is connected to ground.
The 0-20mA / 4-20mA high is connected internally to +24V DC, maximum load 250
S
The 0-50mA is intended for the IMI Electro/Pneumatic converter type 101X.
The +/- 2V and +/- 10V are for the Surface Winder. When Output Trim only - NO is selected the
trim is combined with the line speed signal to provide the total speed demand for the winder drive.
Start in control screen
(No / Yes)
The Controller is despatched from the factory with this set to "No". We recommend that after all
commissioning and set up is finished that this is then set to "Yes". When the Controller is now
switched on, the program is loaded, the company logos are shown briefly and then the Control or
operating screen ready for use by the operator.
Enable MAN / AUTO / OFF keys
(No / Yes)
When using the Digital Inputs to control the sequence of the system, this item should be set to
"No" to prevent accidental operation. The Winder Controllers do not have a MANUAL feature.
Dual tension range
(No / Yes)
Select "Yes" if required. Enter two values of tension. The (normal) value must be the same value
as entered during Calibrate tension. The (low) value should not be less than one third of the
(normal) value. Terminal TB4/11 will be switched OFF when LOW is selected from the front
panel.
TB4/11 is an open drain mosfet which may be used with a suitable electrical relay to select the
pads of a multipad clutch or when the Controller is in Torque Control to select the motor torque
range. See Digital Output Connections for more details.
Minimum tension
Enter a value, the minimum tension is 3%, the maximum is 20%. The system may not function
correctly and may be unsafe if it is operated at zero tension (the motor may run forwards).
