2 S
PECIFICATIONS
Item:
Specification:
Transducer Weight
1T ALUM
1T STEEL
2T STEEL
1.9 lbs.
0.86 kg.
2.7 lb.
1.23 kg
3.7 lb.
1.68 kg
Weight + Mounting Kit
1T
ALUM
1T
STEEL
2T
STEEL
Flange
2.9 lbs.
1.32 kg.
3.7 lbs.
1.68 kg
5.3 lbs.
2.41 kg
Bearing
2.3 lbs.
1.05 kg
.
3.1 lbs.
1.41 kg
.
4.2 lbs.
1.91 kg.
Pillow Block
4.8 lbs
2.18 kg.
5.6 lbs.
2.54 kg.
7.9 lbs.
3.59 kg.
Material
Strain Sensing beam - heat treated 4140 alloy steel
or 2024 T351 Aluminum
Body - 1117 Low Carbon steel
Finish Material
Corrosion resistant Zinc plated with clear Chromate
Bridge Resistance
Steel Transducer: 135-147 Ohms @ 20
o
C
Aluminum Transducer: 122-134 Ohms @ 20
o
Gage Type
Semi-conductor strain gage, gage factor equals 95 (nominal)
Connector Type
M12 Quick-disconnect, 4 conductor, DC keyed
Excitation Voltage
5.6 VDC or VAC (RMS) maximum
(Excess voltage can cause permanent damage)
Nominal Output Signal at Rated
MWF
+/- 350 mV per Transducer (with 5 VDC or VAC rms excitation
voltage)
Output Impedance
Steel Transducer: Approximately 64 Ohms per Bridge leg
Aluminum Transducer: Approximately 60 Ohms per Bridge leg
Non-destructive Overload
150% MWF
Ultimate Overload
300% MWF (typ)
Maximum Voltage, Gage to
Beam or Base (Ground)
50 Volts peak
Angular Deflection
0.01 inches Max. as measured at the far end of the sensing roll
with maximum load present.
Operating Temperature Range
0
o
F to +200
o
F
