1 I
MPORTANT
I
NFORMATION
1.1 O
RDER
N
UMBERS
Use the following example and Tables A, B and C to determine order numbers for:
•
Ultra Series Transducers
•
Mounting Kits
•
Shaft Adapter
Figure 1 – Example for Determining Transducer, Mounting Kit and Shaft Adapter Order Numbers
If you needed to Purchase a Transducer, Mounting Kit and Shaft
Adapter corresponding to following description:
Then, you would use Catalog Numbers:
•
Size 2 cartridge body.
•
Side connection (to allow flange mounting).
•
Maximum Working Force (MWF) of 100 lbs.
•
Shaft Adapter to accommodate 1 inch (outside diameter)
shaft
Ultra Series Transducer = MO-13458-00 (Refer to Table A)
Mounting Kit = MO-04498 (Refer to
Table B
)
Shaft Adapter = MO-12145-1 (Refer to
Table C
)
Having the following information at hand will help you to easily determine which of the Ultra Series Cantilevered
Transducers is right for your application:
•
The desired diameter of the shaft bore
•
The type of electrical connection
•
Maximum working force
Use Table A to determine the catalog number for the proper Cantilevered Transducer.
Table A – Determining a Catalog Number for the Ultra Cantilevered Transducer
Order Code Suffix, M.W.F.
English
Cartridge Size
End
Connector
(CLTEC)
Side
Connector
(CLTSC)
-00
-10
-20
-30
1T ALUM
MO-13453 MO-13454 0.1 lb.
1 lb.
5 lb.
10 lb.
1T STEEL
MO-13455 MO-13456 25 lb.
50 lb.
100 lb.
2T STEEL
MO-13457 MO-13458 100 lb.
250 lb.
500 lb.
Order Code Suffix , Metric M.W.F
Metric
Cartridge Size
End
Connection
(CLTECM)
Side
Connection
(CLTSCM)
-00
-10
-20
-30
1T ALUM
MO-13459
MO-13460
0.5 N
5 N
20 N
45 N
1T STEEL
MO-13461
MO-13462
100 N
200 N
450 N
2T STEEL
MO-13463
MO-13464
450 N
1000 N
2000 N
