8. SPECIFICATION
12
Signal Format NTSC PAL
Image Device 1/3 ˝ 960H SONY EXview HAD CCD II
Scanning System 2 : 1 Interlace
Scanning Frequency 15.734KHz(H), 59.94Hz(V) 15.625KHz(H), 50Hz(V)
Total Pixels 1020(H) X 508(V) 1020(H) X 596(V)
Effective Pixels 976(H) X 494(V) 976(H) X 582(V)
Electronic Shutter Speed 1/60 sec 1/50 sec
H.Resolution 7 50TV Lines
S/N Ratio More than 50dB(AGC OFF)
Min.Illumination
LED Off : COLOR (0.05Lux / F1.2), BW (0.02 Lux / F1.2)
LED On : 0 Lux
Sync System Internal
Gamma r= 0.45
Video Output Level 1.0 Vp-p Composite(75Ω)
OSD Built in (Inner Key / Joystick)
BLC OFF/BLC/HLC
2DNR OFF/ON(Level adjustable)
ATR OFF/ON(Level adjustable)
Function ATW / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH-LOCK
White Balance ATW / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH-LOCK
Privacy Masking 4 Zones
Motion Detection 4 Zones
Day & Night(ICR) AUTO
Language
ENGLISH / JAPANESE / GERMAN / FRENCH / RUSSIAN /
PORTUGUESE / SPANISH / CHINESE
IP Rating IP66 (Weatherproof)
IR LED 940nm, 20ea
IR LED Distance Up to 25M
Operating Temperature 14°F~122°F(-10°C~+50°C)
Storage Temperature -4°F~140°F(-20°C~+60°C)
Humidity Less than 80%
Power
Consumption
DC12V Only : DC12V (±10%), Max.270mA
Dual : DC12V (±10%) Max.360mA , AC24V (±10%) Max.4.9W
Lens Varifocal Lens
Dimension 82.0(W) x 79.3(H) x 145(D)
Weight Approx. 900g
Specifications and designs are subject to change for improving the functionality of this product without notice.
