8 . O p e r a t i n g C a m e r a

Sub-Menu : WDR/ BLC

WDR/BLC

WDR MODE

… ON

WDR LEVEL

… 8

BLC MODE

… OFF

BLC ZONE

… CENTER

BLC LEVEL

… 4

INITIAL

RETURN

• Initializes the changed category in WDR/BLC menu.

• Press the NEAR/FAR button to confirm.

1. WDR MODE(*)

• OFF : Disable the Wide Dynamic Range function

• ON : WDR Fixed mode.

• Can adjust the level(0~15)

2. WDR LEVEL(*)

• Compensates for scenes with "BACKLIGHT"conditions.

3. BLC MODE

• Sets backlight compensation weighting zone(BLC ON mode).

• Can be selected CENTER, TOP, BOTTOM, LEFT, RIGHT.

4. BLC ZONE

• Sets backlight compensation weighting value(BLC ON mode).

• Can be adjusted from 0 to 15.

5. BLC LEVEL

6. INITIAL

• The BLC dose Not Work in WDR ON mode
• (*)The WDR is an Option function

NOTE

BLC
