24
9. OSD MANUAL
• Video
- SDI RESOLUTION
Use the LEFT/RIGHT button to select the SDI
output video resolution - 720p, 1080i, 1080p
* Note : When the OSD menu is not displayed on video,
720p resolution can be selected by pressing the UP
button in 5 seconds. Similarly, 1080p resolution can be
selected by pressisng the DOWN button in 5 seconds.
- SDI FRAME RATE
Use the LEFT/RIGHT button to select the SDI output video frame rate
SDI resolution Available frame rate
1080p 30Hz, 25Hz
1080i 60Hz, 50Hz
720p 30Hz, 25Hz, 60Hz, 50Hz
- CVBS FORMAT
Use the LEFT/RIGHT button to select the TV out video format - NTSC, PAL
* Note : When the OSD menu is not displayed on video, NTSC video format can be selected by pressing
the LEFT button. Similarly, PAL video format can be selected by pressing the RIGHT button.
- VIDEO APPLY
Apply all video setting changed at once. Use the SET button to apply.
- ESC
Back to the prevois menu page.
• LENS
- LENS TYPE
Use the LEFT/RIGHT button to select the lens
type for iris control.
- DC IRIS(VIDEO IRIS), MANUAL IRIS.
- IRIS VOLUME
Use the LEFT/RIGHT button to adjust the iris
volume level.
Iris volume control does not apply when the
LENS TYPE is set to MANUAL IRIS.
VIDEO OUT
＊ SDI RESOLUTION
＊ SDI FRAME RATE
＊ CVBS FORMAT
＋ VIDEO APPLY
＊ ESC
＊ EXIT
1080p
30HZ
NTSC
LENS
＊ LENS TYPE
＊ IRIS VOLUME
＊ ESC
＊ EXIT
DC IRIS
