3 CAMERA SETUP
D-WDR / BLC
MODE HSBLC
LEVEL ···l··· 4
AREA 」
DISP. MODE ALL DAY
RETURN 」
Mode: HSBLC Highlight suppression, strong light sources (e.g. car lamps)
will be blacked out in image
Level Sensitivity trigger level in 9 steps
Area Adjustment of monitored area for HSBLC in a grid 8x8
H.START:
Position of 1. field of area from left (0~7)
V.START:
Position of 1. field of area from top (0~7)
WIDTH:
horizontal size of the area in fields (0~8)
HEIGHT:
vertical size of the area in fields (0~8)
DISP.MODE ALL DAY: HSBLC is always on
NIGHT: HSBLC only active in night mode
