5. INSTALLATION
• MONITOR CONNECTION
DC12V / AC24V
DC12V
11
HD SDI IN
HD SDI IN
SDI
RECEIVER
DISPLAY
DEVICE
SDI
RECEIVER
DISPLAY
DEVICE
RS485(+)
RS485(-)
RS485(+)
RS485(-)
DC12V / AC24V REGULATED
POWER SUPPLY
DC12V REGULATED
POWER SUPPLY
TEST CABLE
When you install the camera, please seal the ends of cables to protect
the camera connections from humidity problems.
HANDHELD
MONITOR
VIDEO IN
TEST CABLE
HANDHELD
MONITOR
VIDEO IN
