20
9. OSD FUNCTION DESCRIPTION
- SYSTEM
1. SHADING DET: Lens shading detection function.
2. DEFECT DET: White pixel detection and compensation function.
3. DOUT FORMAT: Enable user to set up digital output format
(720p, 1080p).
4. DOUT FPS: Enable user to set up digital output frame rate.
5. COLOR BAR: Enable user to set up output colorbar.
6. CVBS: Enable user to set up CVBS type NTSC or PAL.
• FACTORY DEFAULT
: Enable user to reset all of the status as the factory default.
• EXIT
: After saving the current settings in the OSD menu and exit.
SYSTEM
> SHADING DET
DEFECT DET
DOUT FORMAT
DOUT FPS
COLOR BAR
CVBS
COLOR
INITIAL
RETURN
OFF
OFF
1080P
30
OFF
NTSC
