6. INSTALLATION
• MONITOR CONNECTION
11
When you install the camera, please glue up the end of cable to
keep it stable in order to protect the camera from the humidity problems.
VIDEO IN
HANDHELD
MONITOR
Service Video Connector
OPEN
COVER
TEST CABLE
- DC12V/AC24V
- DC12V
- Service Video connector
MONITOR
B N C F E M A L E V I D E O HD SDI IN
DC 12V / AC 24V POWER SUPPLY
SDI
RECEIVER
DISPLAY
DEVICE
MONITOR
BNC FEMALE V I D E O HD SDI IN
DC 12V POWER SUPPLY
SDI
RECEIVER
DISPLAY
DEVICE
