Jungheinrich AM_G20 - Manual (Page 3)

1) + 5 kg at 680 mm width across forks
2) 680 mm also possible
3) Width 520 mm
4) Ø 82x62 mm tandem tyres
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 04/2010
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model AM G20
1.3 Drive manual
1.4 Manual, pedestrian, stand-on, seated, order picker operation hand
1.5 Load capacity/rated load Q t 2
1.6 Load centre distance c mm 400 500 600
1.8 Load distance x mm 535 690 890
1.9 Wheelbase y mm 755 910 1110
W
eights
2.1 Service weight kg 51 1) 54 1) 61 1)
2.3 Axle load, w.o. load, front / rear kg 38 / 20 3)
Wheels / chassis
3.1 Tyres V;N
3.2 Tyre size, at front mm Ø 170x50
3.3 Tyre size, at rear mm Ø 82x96 4)
3.5 Wheels, number front/rear (× = driven wheels) 2/2 or 2/4
3.6 Track width, front b
10
mm 109
3.7 Track width, rear b
11
mm 370
Basic dimensions
4.4 Lift h
3
mm 122
4.9 Height of tiller in drive position min. / max. h
14
mm 1234
4.14 Standing height raised h
12
mm 205
4.15 Lowered height h
13
mm 83
4.19 Overall length l
1
mm 1165 1320 1520
4.20 Length incl. back of forks l
2
mm 373
4.21 Total width b
1
/b
2
mm 520 2)
4.22 Fork dimensions s/e/l mm 53 / 150 / 795 53 / 150 / 950 53 / 150 / 1150
4.25 Width over forks b
5
mm 520 2)
4.32 Floor clearance centre wheelbase m
2
mm 30
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 1584 1584 1734
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 1784
4.35 Turning radius W
a
mm 919 1074 1274
Perform
-
ance da
ta 5.3 Lower speed, w. / w.o. load m/s 0.09 / 0.02
