In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 06/2011
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model AMX I10 AMX I10p AMX I10e AMX I10ep
1.3 Drive manual manual Electrics Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation hand
1.5 Load capacity/rated load Q t 1
1.6 Load centre distance c mm 600
1.8 Load distance x mm 925
1.9 Wheelbase y mm 1140
W
eights
2.1 Service weight kg 108 108 140 140
2.2 Axle load, w. load, front / rear kg 750 / 358 750 / 358 753 / 357 753 / 387
2.3 Axle load, w.o. load, front / rear kg 38 / 70 38 / 70 40 / 100 40 / 100
Wheels / chassis
3.1 Tyres N;V
3.2 Tyre size, at front mm Ø 150x45
3.3 Tyre size, at rear mm Ø 80x60
3.5 Wheels, number front/rear (× = driven wheels) 2/2
3.6 Track width, front b
10
mm 145
3.7 Track width, rear b
11
mm 440
Basic dimensions
4.4 Lift h
3
mm 710
4.9 Height of tiller in drive position min. / max. h
14
mm 1195
4.14 Standing height raised h
12
mm 800
4.15 Lowered height h
13
mm 90
4.19 Overall length l
1
mm 1480 1480 1580 1580
4.20 Length incl. back of forks l
2
mm 340 340 440 440
4.21 Total width b
1
/b
2
mm 540
4.22 Fork dimensions s/e/l mm 50 / 163 / 1140
4.25 Width over forks b
5
mm 540
4.32 Floor clearance centre wheelbase m
2
mm 28
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 1770 1770 1830 1830
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 1830 1830 1890 1890
4.35 Turning radius W
a
mm 1355 1355 1415 1415
Perform
-
ance da
ta 5.3 Lower speed, w. / w.o. load m/s 0.15 / 0.09 0.15 / 0.09 0.08 / 0.05 0.08 / 0.05
Elec
-
trics
6.4 Battery voltage/nominal capacity K5 V/Ah 12 / 60 12 / 60
6.5 Battery weight kg 20 20
