Jungheinrich AM_V05 - Manual (Page 3)

1) Manually adjustable 140-585 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 08/2006
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model AM V05
1.3 Drive manual
1.4 Manual, pedestrian, stand-on, seated, order picker operation hand
1.5 Load capacity/rated load Q t 0.5
1.6 Load centre distance c mm 400
1.8 Load distance x mm 820
1.9 Wheelbase y mm 1120
W
eights
2.1 Service weight kg 155
2.2 Axle load, w. load, front / rear kg 320 / 325
2.3 Axle load, w.o. load, front / rear kg 101 / 54
Wheels / chassis
3.1 Tyres N;C
3.2 Tyre size, at front mm Ø 180 x 50
3.3 Tyre size, at rear mm Ø 82 x 40
3.5 Wheels, number front/rear (× = driven wheels) 2/2
3.6 Track width, front b
10
mm 122
3.7 Track width, rear b
11
mm 700
Basic dimensions
4.4 Lift h
3
mm 390
4.9 Height of tiller in drive position min. / max. h
14
mm 1210
4.15 Lowered height h
13
mm 85
4.19 Overall length l
1
mm 1405
4.20 Length incl. back of forks l
2
mm 450
4.21 Total width b
1
/b
2
mm 760
4.22 Fork dimensions s/e/l mm 50 / 50 / 955
4.25 Width over forks b
5
mm 140 1)
4.26 Width between support arms/loading surfaces b
4
mm 640
4.32 Floor clearance centre wheelbase m
2
mm 30
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 1805
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2005
4.35 Turning radius W
a
mm 1425
Perform
-
ance da
ta 5.3 Lower speed, w. / w.o. load m/s 0.09 / 0.05
