1) Other fork lengths available
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 01/2009
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model AM 30
1.3 Drive manual
1.4 Manual, pedestrian, stand-on, seated, order picker operation hand
1.5 Load capacity/rated load Q t 3
1.6 Load centre distance c mm 600 1050
1.8 Load distance x mm 936 1801
1.9 Wheelbase y mm 1174 2054
W
eights
2.1 Service weight kg 86 142
2.2 Axle load, w. load, front / rear kg 815 / 2270 1135 / 2007
2.3 Axle load, w.o. load, front / rear kg 28 / 58 57 / 85
Wheels / chassis
3.1 Tyres V
3.2 Tyre size, at front mm Ø 200 x 50
3.3 Tyre size, at rear mm Ø 80 x 70
3.5 Wheels, number front/rear (× = driven wheels) 2/4
3.6 Track width, front b
10
mm 116
3.7 Track width, rear b
11
mm 390
Basic dimensions
4.4 Lift h
3
mm 120
4.9 Height of tiller in drive position min. / max. h
14
mm 1224
4.14 Standing height raised h
12
mm 205
4.15 Lowered height h
13
mm 85
4.19 Overall length l
1
mm 1603 2483
4.20 Length incl. back of forks l
2
mm 383
4.21 Total width b
1
/b
2
mm 550
4.22 Fork dimensions s/e/l mm 45 / 160 / 1220 1) 63 / 160 / 2100 1)
4.25 Width over forks b
5
mm 550
4.32 Floor clearance centre wheelbase m
2
mm 36
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 1803 2683
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 1803 2683
4.35 Turning radius W
a
mm 1319 2184
Perform
-
ance da
ta 5.3 Lower speed, w. / w.o. load m/s 0.09 / 0.05
