1) Diagonal in accordance with VDI: + 188 mm
2) Load section lowered: +65 mm
3) Load section lowered: + 95 mm
4) Load section lowered: 90 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 03/2010
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model ESE 120 ESE 120 ESE 220 ESE 320
Rapid
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation stand-on stand-on seat seat
1.5 Load capacity/rated load Q t 2
1.6 Load centre distance c mm 600
1.8 Load distance x mm 964 4) 964 4) 868 868
1.9 Wheelbase y mm 1595 2) 1731 4) 1535 4) 1541 3)
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 857 990 1062 1074
2.2 Axle load, w. load, front / rear kg 1840 / 1017 1900 / 1090 1896 / 1142 1902 / 1182
2.3 Axle load, w.o. load, front / rear kg 215 / 642 240 / 750 258 / 808 264 / 816
Wheels / chassis
3.1 Tyres Polyurethan
3.2 Tyre size, at front mm Ø 230 x 78
3.3 Tyre size, at rear mm Ø 85 x 85
3.4 Additional wheels (dimensions) mm Ø 140 x 54
3.5 Wheels, number front/rear (× = driven wheels) 2+1x/4 1+1x/4 2-1x/4 2-1x/4
3.6 Track width, front b
10
mm 475 475 544 645
3.7 Track width, rear b
11
mm
340 / 370 /
490
340 / 370 /
490
385 385
Basic dimensions
4.4 Lift h
3
mm 125
4.8 Seat height/stand height h
7
mm 1020 1020
4.8.1 Standing height h
7
mm 245 245
4.15 Lowered height h
13
mm 90
4.19 Overall length l
1
mm 2024 2096 2113 2118
4.20 Length incl. back of forks l
2
mm 874 946 854 859
4.21 Total width b
1
/b
2
mm 760 760 820 930
4.22 Fork dimensions s/e/l mm
55 / 170 /
1150
55 / 170 /
1150
60 / 185 /
1150
60 / 185 /
1150
4.25 Width over forks b
5
mm 510 / 540 510 / 540 540 540
4.32 Floor clearance centre wheelbase m
2
mm 30 30 25 25
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2274 1) 2346 1) 2197 1) 2215 1)
4.35 Turning radius W
a
mm 1838 1910 1665 1683
Performance
da
ta
5.1 Travel speed, w. / w.o. load km/h 8.5 / 10.5 9.5 / 12.5 10 / 12.5 10 / 12.5
5.2 Lift speed, w. / w.o. load m/s 0.04 / 0.05 0.04 / 0.05 0.06 / 0.07 0.06 / 0.07
5.3 Lower speed, w. / w.o. load m/s 0.065 / 0.045 0.065 / 0.045 0.06 / 0.05 0.06 / 0.05
5.8 Max. gradeability, laden/unladen % 6 / 12 6 / 12 8 / 13 8 / 13
5.10 Service brake electric
Electrics
6.1 Drive motor rating S2 60 min. kW 2.0 2.5 2.8 2.8
6.2 Lift motor rating at S3 15% kW 2.0 2.0 1.5 1.5
6.3 Battery according to DIN 43531/35/36 A,B,C, no B B no no
6.4 Battery voltage/nominal capacity K5 V/Ah 24 / 375 24 / 500 24 / 465 24 / 465
6.5 Battery weight kg 297 370 380 380
Misc.
8.1 Type of drive control SpeedControl SpeedControl
AC
SpeedControl
AC
SpeedControl
