1) Lowered / raised
2) Power 1st motor / Power 2nd motor
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 02/2010
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model ESE 533
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation seat
1.5 Load capacity/rated load Q t 3.3
1.6 Load centre distance c mm 1800
1.8 Load distance x mm 2630
1.9 Wheelbase y mm 3770 / 3720 1)
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 3480
2.2 Axle load, w. load, front / rear kg 3460 / 3320
2.3 Axle load, w.o. load, front / rear kg 2750 / 730
Wheels / chassis
3.1 Tyres Vulkollan
3.2 Tyre size, at front mm Ø 343 x 140
3.3 Tyre size, at rear mm Ø 90 x 100
3.5 Wheels, number front/rear (× = driven wheels) 2x /4
3.6 Track width, front b
10
mm 592
3.7 Track width, rear b
11
mm 380
Basic dimensions
4.4 Lift h
3
mm 115
4.8 Seat height/stand height h
7
mm 1470
4.15 Lowered height h
13
mm 95
4.19.1 total length (long) mm 4895
4.20 Length incl. back of forks l
2
mm 1295
4.21 Total width b
1
/b
2
mm 1000
4.22 Fork dimensions s/e/l mm 70 / 200 / 3600
4.25 Width over forks b
5
mm 580
4.32 Floor clearance centre wheelbase m
2
mm 20
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 5196
4.35 Turning radius W
a
mm 3982 / 3922 1)
Performance
da
ta
5.1 Travel speed, w. / w.o. load km/h 19 / 20
5.2 Lift speed, w. / w.o. load m/s 0.056 / 0.06
5.3 Lower speed, w. / w.o. load m/s 0.052 / 0.05
5.7 Gradeability laden/unladen % 5 / 10
5.10 Service brake electric
Electrics
6.1 Drive motor rating S2 60 min. kW 6.9 / 6,9 2)
6.2 Lift motor rating at S3 15% kW 3.0
6.3 Battery according to DIN 43531/35/36 A,B,C, no no
6.4 Battery voltage/nominal capacity K5 V/Ah 48 / 1000
6.5 Battery weight kg 1450
Misc.
8.1 Type of drive control Mosfet / AC
