Benefit from the advantages
In operation in a store
Innovative 3-phase AC technology
Jungheinrich 3-phase AC motors offer
greater performance whilst at the same
time reducing operating costs over the
entire life of the truck:
• High efficiency levels with excellent
energy management.
• Powerful acceleration.
• Stepless smooth control of the travel
speed via the travel switch.
• Rapid travel direction change without
pause.
• No carbon brushes – maintenance-
free drive motor.
• Two year warranty on the drive motor.
Optimum cornering
Sprung and hydraulically cushioned sup-
port wheels linked via the ProTracLink
torsion bar – distribute equalising forces
dependent on travel conditions i.e.
evenly across all wheels during straight-
line travel; concentrated on the outer
support wheel during cornering.
Fully informed at all times
Extensive instrument display and setting
options allow the operator to monitor
the situation at a glance:
• Discharge indicator (3 colour LED) with
lift cut-out.
• Adjustable drive parameters through
CanDis and CanCode (optional).
• CanDis information display (optional)
with additional service hour display and
service data storage.
• PIN activation of truck and choice of
3 travel programmes via CanCode
(optional).
Comfortable operation
The SpeedControl impulse control sys-
tem facilitates comfortable, safe travel:
• The speed set by the drive switch is
maintained under all travel conditions
– even on gradients / descents.
• If the EJE C20 starts to roll away on the
ramp it brakes automatically.
• Individually adjustable drive parameters
(acceleration, top speed, motor brake)
enable the truck to be tailored to
individual requirements.
• The operator may choose from 3 dif-
ferent travel programs (optional).
• Energy recovery through regenerative
braking on deceleration.
• Very low noise level when travelling.
Reduced maintenance costs
Service-friendly components ensure a
significant long-term reduction in oper-
ating costs:
• Maintenance-free AC drive motor with
no carbon brushes.
• Easy access to all parts with one-piece
front panel with just 2 screws.
• Excellent protection against dust and
humidity through enclosure of con-
troller and connectors to IP 54.
• The ProtracLink technology reduces
tyre wear when operating on a ramp
due to equalising effect of the torsion
bar. This bar also keeps the support
wheels at the same height and when
they go over the edge of a loading
dock or dock-leveller, unlike a spring
loaded wheel they easily drive back
into dafety.
Optimum pallet handling
• Enclosed skids on both fork tips for
easy entry into empty Euro or per-
imeter based pallets.
• Separate control of mast and support
arm lift to remove semi / quarter pallets
from Euro pallets (option).
Long uptimes
The energy-saving 3-phase AC system
combined with a 250 Ah battery capacity
ensures long operation times:
• 2 PzB 200 Ah batteries for vertical
battery removal.
• Sideways battery removal (optional) for
2 PzB 250 Ah batteries.
• On-board charger (24V/30 A for wet
cell batteries and maintenance-free
batteries) for easy charging at any
mains socket (optional).
Optional equipment
• Writing pad with light
• Load backrest.
• Special key switch for easy brake
release.
• Cold store version.
