1) Diagonal in accordance with VDI: depending on width over support arms 133/133/209 mm
2) Diagonal in accordance with VDI: depending on width over support arms 203/203/259 mm
3) DZ: x -3 mm; l1 +3 mm; l2 +3 mm
4) Tiller in upright position (crawl speed)
5) Values for 290 ZT standard mast; 280 ZT and with battery as per line 6.5
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 11/2012
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EJC B12 5) EJC B14 5) EJC B16 5) EJC B20 5)
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation pedestrian
1.5 Load capacity/rated load Q t 1.2 1.4 1.6 2
1.6 Load centre distance c mm 600
1.8 Load distance x mm 703 3) 668 3) 668 3) 668 3)
1.9 Wheelbase y mm 1339 1409 1409 1409
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 1065 1146 1146 1322
2.2 Axle load, w. load, front / rear kg 800 / 1465 822 / 1724 828 / 1918 880 / 2442
2.3 Axle load, w.o. load, front / rear kg 730 / 335 753 / 393 753 / 393 850 / 472
Wheels / chassis
3.1 Tyres PU
3.2 Tyre size, at front mm Ø 230 x 70
3.3 Tyre size, at rear mm Ø 85 x 75
3.4 additional wheels (dimensions) mm Ø 140 x 57
3.5 Wheels, number front/rear (× = driven wheels) 1x+1/4
3.6 Track width, front b
10
mm 507
3.7 Track width, rear b
11
mm 1000 / 1170 / 1370
Basic dimensions
4.2 Mast height (lowered) h
1
mm 1950 1950 1950 2100
4.3 Free lift h
2
mm 100
4.4 Lift h
3
mm 2900 2900 2800 2800
4.5 Extended mast height h
4
mm 3470 3470 3370 3477
4.9 Height of tiller in drive position min. / max. h
14
mm 850 / 1305
4.15 Lowered height h
13
mm 70
4.19 Overall length l
1
mm 1955 3) 2060 3) 2060 3) 2060 3)
4.20 Length incl. back of forks l
2
mm 805 3) 910 3) 910 3) 910 3)
4.21 Total width b
1
/b
2
mm 1100 / 1470
4.22 Fork dimensions s/e/l mm
40 / 100 /
1150
40 / 100 /
1150
40 / 100 /
1150
50 / 140 /
1150
4.23 Fork carriage ISO 2328, class/type A, B 2A 2A 2A 2B
4.24 Fork carriage width b
3
mm 800
4.25 Width over forks b
5
mm 706
4.31 Floor clearance with load under mast m
1
mm 40
4.32 Floor clearance centre wheelbase m
2
mm 50
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 2197 2) 2302 2) 2302 2) 2302 2)
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2247 1) 2352 1) 2352 1) 2352 1)
4.35 Turning radius W
a
mm 1550 4) 1620 4) 1620 4) 1620 4)
Performance
da
ta
5.1 Travel speed, w. / w.o. load km/h 6 / 6 6 / 6 6 / 6 5.3 / 6
5.2 Lift speed, w. / w.o. load m/s 0.13 / 0.22 0.16 / 0.25 0.15 / 0.25 0.1 / 0.18
5.3 Lower speed, w. / w.o. load m/s 0.43 / 0.37 0.37 / 0.34 0.37 / 0.34 0.37 / 0.34
5.8 Max. gradeability, laden/unladen % 8 / 16 8 / 16 7 / 16 5 / 16
5.10 Service brake generated
Electrics
6.1 Drive motor rating S2 60 min. kW 1.0 1.6 1.6 1.6
6.2 Lift motor, output at S3 (on time) 11 % kW 3 3 3
6.2 Lift motor, output at S3 (on time) 12 % kW 2
6.3 Battery according to DIN 43531/35/36 A,B,C, no 3 PzB 3 PzS 3 PzS 3 PzS
6.4 Battery voltage/nominal capacity K5 V/Ah 24 / 300 24 / 375 24 / 375 24 / 375
6.5 Battery weight kg 250 288 288 288
6.6 Energy consumption according to VDI cycle kWh/h 0.93 1.25 1.31
Misc.
8.1 Type of drive control AC SpeedControl
8.4
Sound pressure level at operator’s ear according to EN
12053
dB (A) 63
