1) 375 Ah = 288 kg, 465 Ah = 368 kg
2) Battery compartment L + 27 mm / L high + 72 mm
3) Battery compartment L = 375 Ah, L high = 465 Ah
4) Diagonal in accordance with VDI: + 225 mm
5) Diagonal in accordance with VDI: + 369 mm
6) Load section lowered: + 48 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may result in
different values.
Technical data in line with VDI 2198
Issue: 10/2010
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model ERD 220
Basis Foldable platform fixed platform
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation
stand-on/pedes-
trian
stand-on/pedes-
trian
stand-on
1.5 Load capacity/rated load Q t 2
1.5.1 Load capacity/mast lift Q t 1
1.5.2 Load capacity/support arm lift Q t 2
1.6 Load centre distance c mm 600
1.8 Load distance x mm 957 6)
1.9 Wheelbase y mm 1749 6) 1677 6) 1677 6)
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 1186 1110 1168
2.2 Axle load, w. load, front / rear kg 1958 / 1228 1920 / 1190 1920 / 1248
2.3 Axle load, w.o. load, front / rear kg 348 / 838 310 / 800 310 / 858
Wheels / chassis
3.1 Tyres Vulkollan
3.2 Tyre size, at front mm Ø 230 x 77
3.3 Tyre size, at rear mm Ø 85 x 95 / Ø 85 x 75
3.4 Additional wheels (dimensions) mm Ø 140 x 50
3.5 Wheels, number front/rear (× = driven wheels) 1x +2/2 4
3.6 Track width, front b
10
mm 512
3.7 Track width, rear b
11
mm 385
Basic dimensions
4.2 Mast height (lowered) h
1
mm 1350
4.4 Lift h
3
mm 1660
4.5 Extended mast height h
4
mm 2150
4.6 Initial lift h
5
mm 122
4.9 Height of tiller in drive position min. / max. h
14
mm 1158 / 1414
4.15 Lowered height h
13
mm 90
4.19 Overall length l
1
mm 2246 2174 2) 2584 2)
4.20 Length incl. back of forks l
2
mm 1056 984 2) 1394 2)
4.21 Total width b
1
/b
2
mm 770
4.22 Fork dimensions s/e/l mm 56 / 185 / 1190
4.25 Width over forks b
5
mm 570
4.32 Floor clearance centre wheelbase m
2
mm 20
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 2455 5) 2383 5) 2831 5)
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2465 4) 2393 4) 2841 4)
4.35 Turning radius W
a
mm 2022 6) 1950 6) 2398 6)
Performance
da
ta
5.1 Travel speed, w. / w.o. load km/h 7.2 / 8.2 9.5 / 12.5 9.5 / 12.5
5.2 Lift speed, w. / w.o. load m/s 0.13 / 0.22 0.14 / 0.24 0.14 / 0.24
5.3 Lower speed, w. / w.o. load m/s 0.25 / 0.21 0.27 / 0.25 0.27 / 0.25
5.8 Max. gradeability, laden/unladen % 8 / 15 8 / 16 8 / 16
5.10 Service brake generated
Electrics
6.1 Drive motor rating S2 60 min. kW 2.8
6.2 Lift motor kW rating at S3 7% kW 2.0
6.2 Lift motor, output at S3 (on time) 12 % kW 2 2
6.3 Battery according to DIN 43531/35/36 A,B,C, no B 43535
6.4 Battery voltage/nominal capacity K5 V/Ah 24 / 375 24 / 250 3) 24 / 250 3)
6.5 Battery weight kg 288 220 1) 220 1)
6.6 Energy consumption according to VDI cycle kWh/h 0.51 0.67 0.67
6.7 Throughput efficiency t/h 94 94
6.8 Energy consumption at max. throughput kWh/h 0.61 0.61
Misc.
8.1 Type of drive control AC SpeedControl
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 63 67 67
