In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 04/2008
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EJC i12z
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation tiller
1.5 Load capacity/rated load Q t 1.2
1.6 Load centre distance c mm 600
1.8 Load distance x mm 808
1.9 Wheelbase y mm 1525
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 1309
2.2 Axle load, w. load, front / rear kg 991 / 1369
2.3 Axle load, w.o. load, front / rear kg 854 / 306
Wheels / chassis
3.1 Tyres PU
3.2 Tyre size, at front mm 230 x 70
3.3 Tyre size, at rear mm 82 x 66
3.4 Additional wheels (dimensions) mm 125 x 54
3.5 Wheels, number front/rear (× = driven wheels) 2-1x/4
3.6 Track width, front b
10
mm 464
3.7 Track width, rear b
11
mm 380
Basic dimensions
4.2 Mast height (lowered) h
1
mm 1780
4.3 Free lift h
2
mm 200
4.4 Lift h
3
mm 2500
4.5 Extended mast height h
4
mm 2980
4.6 Initial lift h
5
mm 114
4.9 Height of tiller in drive position min. / max. h
14
mm 861 / 1523
4.15 Lowered height h
13
mm 90
4.19 Overall length l
1
mm 2084
4.20 Length incl. back of forks l
2
mm 934
4.21 Total width b
1
/b
2
mm 785
4.22 Fork dimensions s/e/l mm 55 / 180 / 1150
4.25 Width over forks b
5
mm 560
4.32 Floor clearance centre wheelbase m
2
mm 21
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2505
4.35 Turning radius W
a
mm 1745
Performance
da
ta
5.1 Travel speed, w. / w.o. load km/h 5.3 / 5.3
5.2 Lift speed, w. / w.o. load m/s 0.04 / 0.06
5.3 Lower speed, w. / w.o. load m/s 0.059 / 0.053
5.8 Max. gradeability, laden/unladen % 8 / 15
5.10 Service brake electric
Electrics
6.1 Drive motor rating S2 60 min. kW 1.6
6.2 Lift motor rating at S3 15% kW 2.2
6.3 Battery according to DIN 43531/35/36 A,B,C, no B
6.4 Battery voltage/nominal capacity K5 V/Ah 24 / 250
6.5 Battery weight kg 220
Misc.
8.1 Type of drive control AC SpeedControl
