Technical data in line with VDI 2198
as at: 08/2010
1.1 Manufacturer (abbreviation) Jungheinrich Jungheinrich Jungheinrich Jungheinrich 1.1
1.2 Manufacturer’s type designation EJG 106 EJG 108 EJG 110 EJG 112 1.2
1.3 Drive electric electric electric electric 1.3
1.4 Operator type pedestrian pedestrian pedestrian pedestrian 1.4
1.5 Load capacity / rated load Q (t) 0.6 0.8 1.0 1.2 1.5
1.6 Load centre distance c (mm) 500 500 500 500 1.6
1.8 Load distance, centre of drive axle to fork x (mm) 120 120 120 120 1.8
1.9 Wheelbase y (mm) 960 1090 1220 1350 1.9
2.1 Service weight incl. battery (see line 6.5) kg 1980 2045 2110 2175 2.1
2.2 Axle loading, laden front / rear kg 550 / 2030 550 / 2295 550 / 2560 550 / 2825 2.2
2.3 Axle loading, unladen front / rear kg 1000 / 980 1030 / 1015 1070 / 1040 1100 / 1075 2.3
3.1 Tyres PU / Vulkollan ® PU / Vulkollan ® PU / Vulkollan ® PU / Vulkollan ® 3.1
3.2 Tyre size, front mm л 230 x 70 л 230 x 70 л 230 x 70 л 230 x 70 3.2
3.3 Tyre size, rear mm л 200 x 100 л 200 x 100 л 200 x 100 л 200 x 100 3.3
3.5 Wheels, number front rear (x = driven wheels) 1x / 2 1x / 2 1x / 2 1x / 2 3.5
4.2 Closed mast height h
1
(mm) 1880 1880 1880 1880 4.2
4.3 Free lift h
2
(mm) 100 100 100 100 4.3
4.4 Lift h
3
(mm) 2500 2500 2500 2500 4.4
4.9 Height of tiller in drive position min. / max. h
14
(mm) 865 / 1320 865 / 1320 865 / 1320 865 / 1320 4.9
4.15 Height, lowered h
13
(mm) 50 50 50 50 4.15
4.19 Overall length l
1
(mm) 2400 2530 2660 2790 4.19
4.20 Length to face of forks l
2
(mm) 1250 1380 1510 1640 4.20
4.21 Overall width b
1
/ b
2
(mm) 910 / – 910 / – 910 / – 910 / – 4.21
4.22 Fork dimensions s /e / l (mm) 40 / 80 / 1150 40 / 80 / 1150 40 / 80 / 1150 40 / 80 / 1150 4.22
4.24 Fork-carriage width b
3
(mm) 680 680 680 680 4.24
4.31 Ground clearance, laden, below mast m
1
(mm) 60 60 60 60 4.31
4.32 Ground clearance, centre of wheelbase m
2
(mm) 90 90 90 90 4.32
4.34 Aisle width for pallets 800 x1200 lengthways Ast (mm) 2730 2860 2990 3120 4.34
4.35 Turning radius Wa (mm) 1180 1310 1440 1570 4.35
5.1 Travel speed, laden / unladen km/h 4.6 / 5.2 4.6 / 5.2 4.6 / 5.2 4.6 / 5.2 5.1
5.2 Lift speed, laden / unladen m/s 0.13 / 0.20 0.13 / 0.20 0.13 / 0.20 0.13 / 0.20 5.2
5.3 Lowering speed, laden / unladen m/s 0.43 / 0.40 0.43 / 0.40 0.43 / 0.40 0.43 / 0.40 5.3
5.10 Service brake electric electric electric electric 5.10
6.1 Drive motor rating S
2
60 min. kW 1 1 1 1 6.1
6.2 Lift motor rating at S
3
10% kW 1.7 1.7 1.7 1.7 6.2
6.3 Battery acc. to DIN 43531 / 35 / 36 A, B, C, no A A A A 6.3
6.4 Battery voltage, nominal capacityt K
5
V/Ah 24 / 375 24 / 375 24 / 375 24 / 375 6.4
6.5 Battery weight kg 306 306 306 306 6.5
8.1 Type of drive control AC SpeedControl AC SpeedControl AC SpeedControl AC SpeedControl 8.1
Identification
W
eights
Wheels, Chassis
Basic Dimensions
Performance Data
E-Motor
Others
This specification sheet according to VDI regulation 2198 only provides technical values for the standard truck. Non-standard tyres, different masts, additional equipment, etc. could produce
other values. Right reserved for technical changes and improvements.
