Ergonomic cabin
Comfortable, performance orientated
ergo nomics.
• Easy truck entry and exit; low step
position, easily seen from above.
• Operator cabin completely sealed from
engine and suppressed against noise
and vibration.
• Smoothly adjustable and mechanically
cushioned comfort seat (air cushioning
optional).
• Adjustable steering column.
• Hydraulic levers fixed to the operator
seat (SOLO-PILOT) automatically move
with all seat adjustments.
• Travel direction switch on the steering
column (optionally available integrated
into the MULTI-PILOT control lever).
• Extensive, comfortable leg room with
combined brake/inch pedal.
• Excellent visibility through the mast
due to the location of hydraulic cylin-
ders hidden behind the mast profiles.
• Comfortable operation in all weather
conditions with the comprehensively
equipped standard cabin.
• Specially designed roof and cabin sides
offering exceptional all-round visibility
• 180 degrees swivelling (left) seat
(optional).
Powerful engines
The turbo diesel industrial engines are
specially designed for the required drive
power in fork lift truck applications.
• DFG 660–690 and S80: 4-cylinder-
turbo diesel engine (4.4-l-Perkins) with
electronic injection producing 91 kW at
2200 r.p.m. Maximum Torque: 490 Nm
at 1400 r.p.m.
• DFG S90: 6-cylinder-turbo diesel
engine (6.6-l-Perkins) with elec-
tronic injection producing 90 kW at
2200 r.p.m. Maximum Torque: 545 Nm
at 1400 r.p.m.
• Exhaust emissions below emission
values in accordance with ISO 8178
(fulfils exhaust emission part 3a for
diesel engines).
• Particle/soot filter (optional).
• 115 litre fuel tank integrated into chassis.
Strong hydrodynamic drive
The hydrodynamic drive with elec-
tronically controlled 2 speed power shift
transmission ensures an economic trans-
mission of power. Other advantages:
• Precise and smooth power transmission.
• Automatic shift and electronically
controlled shift lock at travel speeds of
more than 4 km/h.
• Inch pedal (combined crawl-speed/
brake pedal) for precise travel during
full lift capacity.
• Travel comfort packet (optional) with
automatic increase in rpm during
lifting, hydrostatic handling and large
multifunction display. Especially suited
for reversing and manoeuvring.
Service
Low service costs through good
accessibility.
• Tiltable cabin – hinged at the rear and
hydraulically operated.
• Simple access for daily maintenance
(oil and water).
• Long service intervals of 500 hours.
Intelligent electronics
• Splash proof electronic drive and
hydraulic controllers (in accordance
with IP 64) connected via CAN-Bus.
• 12 Volt battery, 135 Ah/115 A alternator.
• Precise control of hydraulic functions
using electromagnetic valves.
Precise steering
The maximum in steering comfort and
highest safety through;
• Hydrostatic steering for extremely light
and precise steering.
• Steering axle with integrated steer
cylinder.
Brakes
Two independent braking systems on the
front wheels.
• Foot brake – hydraulic servo; mainte-
nance free, encapsulated oil laminate
brakes with servo assistance.
• Parking brake: electro-hydraulic disc
brakes operated via a button located
on the display.
Reliable hydraulics
• Fine particle filtration in the fluid return
circuit.
• 180 litre hydraulic tank integrated into
the chassis.
• Filtration of hydraulic tank ventilator.
• Pressure release valves protect against
over pressurisation and overload.
Strong mast
• Slim mast profiles with lift cylinders
hidden behind allow an extra wide
window of visibility.
• Optimised view through the fork
carriage.
• Fork carriage in accordance with
FEM/ISO-2328-4A.
Additional equipment
Many custom build options and various
attachments are available in order to
adapt the truck to suit customer requests
or different applications.
Make use of the advantages
Operator cabin
