DFG/TFG 425/430/435
Standard mast types DFG 425/DFG 430/DFG 435/TFG 425/TFG 430/TFG 435
Lift
h
3
Lowered mast height
h
1
Free lift
h
2
Extended mast height
h
4
Mast tilt forward /
back
α/ β
(mm) (mm) (mm) (mm) (°)
DFG 425 /
TFG 425
DFG 430 /
TFG 430
DFG 435 /
TFG 435
DFG 425 /
TFG 425
DFG 430 /
TFG 430
DFG 435 /
TFG 435
DFG 425 /
TFG 425
DFG 430 /
TFG 430
DFG 435 /
TFG 435
DFG 425 /
DFG 430 /
TFG 425 /
TFG 430
DFG 435 /
TFG 435
Duplex ZT 2900 2129 2122 2201 150 150 150 3502 3659 3689 6/8 6/8
3100 2229 2222 2301 150 150 150 3702 3859 3889 6/8 6/8
3300 2329 2322 2401 150 150 150 3902 4059 4089 6/8 6/8
3500 2429 2422 2501 150 150 150 4102 4259 4289 6/8 6/8
3700 2529 2522 2601 150 150 150 4302 4459 4489 6/8 6/8
4000 2679 2672 2751 150 150 150 4602 4759 4789 6/8 6/8
4300 2879 2872 2951 150 150 150 4902 5059 5089 6/8 6/8
4500 2979 2972 3051 150 150 150 5102 5259 5289 6/8 6/6
Duplex ZZ 3100 2194 2187 2266 1614 1448 1497 3680 3839 3869 6/8 6/8
3300 2294 2287 2366 1714 1548 1597 3880 4039 4069 6/8 6/8
3500 2394 2387 2466 1814 1648 1697 4080 4239 4269 6/8 6/8
3700 2494 2487 2566 1914 1748 1797 4280 4439 4469 6/8 6/8
4000 2644 2637 2716 2064 1898 1947 4580 4739 4769 6/8 6/8
Triplex DZ 4400 2094 2087 2166 1514 1348 1397 4980 5139 5169 6/8 6/6
4700 2194 2187 2266 1614 1448 1497 5280 5439 5469 6/6 6/6
5000 2294 2287 2366 1714 1548 1597 5580 5739 5769 6/6 6/6
5500 2494 2487 2566 1914 1748 1797 6080 6239 6269 6/6 6/6
6000 2694 2687 2766 2114 1948 1997 6580 6739 6769 6/6 6/6
6500 2894 2887 2966 2314 2148 2197 7080 7239 7269 6/6 6/6
7000 3094 3087 3166 2514 2348 2397 7580 7739 7769 6/6 6/6
7500 3294 3287 3366 2714 2548 2597 8080 8237 8269 6/6 6/6
