1)
+10 mm with DZ mast
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 08/2013
Identifica
tion
1.1
Manufacturer (short form)
Jungheinrich
1.2
Model
DFG
540s
DFG
545s
DFG
550s
DFG
S50s
TFG
540s
TFG
545s
TFG
550s
TFG
S50s
1.3
Drive
Diesel
Diesel
Diesel
Diesel
LPG
LPG
LPG
LPG
1.4
Manual, pedestrian, stand-on, seated, order picker operation
seat
1.5
Load capacity/rated load
Q t
4
4.5
4.99
5
4
4.5
4.99
5
1.6
Load centre distance
c mm
500
500
500
600
500
500
500
600
1.8
Load distance
x mm
564
1)
564
1)
564
1)
579
1)
564
1)
564
1)
564
1)
579
1)
1.9
wheelbase
y mm
1970
1970
1970
2000
1970
1970
1970
2000
W
eights
2.1
Service weight
kg
6310
6550
7200
7400
6360
6600
7250
7450
2.2
Axle load, w. load, front / rear
kg
9050 /
1260
9660 /
1390
10940
/ 1260
10900
/ 1500
9070 /
1290
9680 /
1420
10960
/ 1290
10920
/ 1530
2.3
Axle load, w.o. load, front / rear
kg
2920 /
3390
2730 /
3820
3240 /
3960
3000 /
4400
2950 /
3410
2760 /
3840
3270 /
3980
3030 /
4420
Wheels / chassis
3.1
Tyres
SE
3.2
Tyre size, at front
mm
8.25-
15
300-15 300-15 300-15
8.25-
15
300-15 300-15 300-15
3.3
Tyre size, at rear
mm
28x9-15
3.5
Wheels, number front/rear (× = driven wheels)
2x/2
3.6
Track width, front
b
10
mm
1195
1160
1160
1160
1195
1160
1160
1160
3.7
Track width, rear
b
11
mm
1150
Basic dimensions
4.1
Tilt of mast/fork carriage forward/backward
α/
β °
6/8
4.2
mast height (lowered)
h
1
mm
2540
4.3
Free lift
h
2
mm
150
4.4
Lift
h
3
mm
3500
4.5
Extended mast height
h
4
mm
4215
4215
4365
4365
4215
4215
4365
4365
4.7
Height of overhead guard
h
6
mm
2405
4.8
Seat height/stand height
h
7
mm
1230
4.12
Coupling height
h
10
mm
510
4.19
Overall length
l
1
mm
4145
4220
4240
4310
4145
4220
4240
4310
4.20
Length incl. back of forks
l
2
mm
2995
3070
3090
3160
2995
3070
3090
3160
4.21
Total width
b
1
/b
2
mm
1450
4.22
fork dimensions
s/e/l mm
50 /
125 /
1150
50 /
150 /
1150
50 /
150 /
1150
60 /
150 /
1150
50 /
125 /
1150
50 /
150 /
1150
50 /
150 /
1150
60 /
150 /
1150
4.23
Fork carriage ISO 2328, class/type A, B
3A
3A
3A
4A
3A
3A
3A
4A
4.24
fork carriage width
b
3
mm
1260
4.31
floor clearance with load under mast
m
1
mm
175
4.32
Floor clearance centre wheelbase
m
2
mm
200
4.33
Aisle width for pallets 1000 × 1200 sideways
Ast mm
4405
4465
4475
4530
4405
4465
4475
4530
4.34
Aisle width for pallets 800 × 1200 lengthways
Ast mm
4605
4665
4675
4730
4605
4665
4675
4730
4.35
turning radius
W
a
mm
2640
2700
2710
2750
2640
2700
2710
2750
4.36
Smallest pivot point distance
b
13
mm
730
Performance da
ta
5.1
Travel speed, w. / w.o. load
km/h
21
5.2
Lift speed, w. / w.o. load
m/s
0.53 /
0.56
0.51 /
0.55
0.49 /
0.53
0.49 /
0.53
0.53 /
0.56
0.51 /
0.55
0.49 /
0.53
0.49 /
0.53
5.3
Lower speed, w. / w.o. load
m/s
0.57 / 0.54
5.5
Drawbar pull w. / w.o. load
N
23000
22000
22000
22000
23000
22000
22000
22000
5.7
Gradeability laden/unladen
%
25 / 27
23 / 26
22 / 26
21 / 25
25 / 27
23 / 26
22 / 26
21 / 25
5.9
Acceleration time w. / w.o. load
S
5.7 / 5
6 / 5.2
6 / 5.2
6.2 /
5.5
5.7 / 5
6 / 5.2
6 / 5.2
6.2 /
5.5
5.10
Service brake
hydrostatic
5.11
parking brake
Automatic activated multi disc brake
Combustion engine
7.1
Motor manufacturer / type
VW /
2,0 CR
VW /
2,0 CR
VW /
2,0 CR
VW /
2,0 CR
VW /
3.6VR6
VW /
3.6VR6
VW /
3.6VR6
VW /
3.6VR6
7.2
motor output according to ISO 1585
kW
55
55
55
55
59
59
59
59
7.3
rated revolutions per minute
/min
2700
7.4
No. of cylinders
4
4
4
4
6
6
6
6
7.4.1
cubic capacity
cm³
1968
1968
1968
1968
3597
3597
3597
3597
7.5
fuel consumption acc. to VDI cycle
l/h
4.4
4.8
5
5.2
7.5.1
fuel consumption acc. to VDI cycle
kg/h
4.3
4.5
4.7
4.8
Misc.
8.1
type of drive control
hydrostatic
8.2
working pressure for attachments
bar
170
8.3
oil flow for attachments
l/min
48
8.4
Sound pressure level at operator’s ear according to EN 12053
dB (A)
77
77
77
77
78
78
78
78
8.5
Trailer coupling, model/type DIN
DIN 15170 Typ H
