EFG 425k/425/430k/430/S30
Standard mast types EFG 425k/425/430k/430/S30
Lift
h
3
Lowered mast height
h
1
Free lift
h
2
Extended mast height
h
4
Mast tilt for-
ward / back
α/ β
(mm) (mm) (mm) (mm) (°)
EFG 425k / 425 EFG 430k / 430
/ S30
EFG 425k / 425 EFG 430k / 430
/ S30
EFG 425k / 425 EFG 430k / 430
/ S30
Duplex ZT 2900 2125 2122 150 150 3502 3659 6/8
3100 2225 2222 150 150 3702 3859 6/8
3300 2325 2322 150 150 3902 4059 6/8
3500 2425 2422 150 150 4102 4259 6/8
3700 2525 2522 150 150 4302 4459 6/8
4000 2675 2672 150 150 4602 4759 6/8
4300 2875 2872 150 150 4902 5059 6/8
4500 2975 2972 150 150 5102 5259 6/8
Duplex ZZ 3100 2190 2187 1609 1448 3680 3839 6/8
3300 2290 2287 1709 1548 3880 4039 6/8
3500 2390 2387 1809 1648 4080 4239 6/8
3700 2490 2487 1909 1748 4280 4439 6/8
4000 2640 2637 2059 1898 4580 4739 6/8
Triplex DZ 4400 2090 2087 1509 1348 4980 5139 6/8
4700 2190 2187 1609 1448 5280 5439 6/5.5
5000 2290 2287 1709 1548 5580 5739 6/5.5
5500 2490 2487 1909 1748 6080 6239 6/5.5
6000 2690 2687 2109 1948 6580 6739 6/5.5
6500 2890 2887 2309 2148 7080 7239 6/3
7000 3090 3087 2509 2348 7580 7739 6/3
7500 3290 3287 2709 2548 8080 8239 6/3
