1) 365 mm for DZ mast; for integral sideshift: x = 363 mm (388 mm for DZ mast); for sideshift attachment: x = 400 mm (425 mm for DZ mast)
2) 60 VDI work cycles/h, tolerances +/- 10 % possible
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 07/2010
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EFG 316k EFG 316 EFG 318k EFG 318 EFG 320
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation seat
1.5 Load capacity/rated load Q t 1.6 1.6 1.8 1.8 2
1.6 Load centre distance c mm 500
1.8 Load distance x mm 340 1)
1.9 Wheelbase y mm 1400 1508 1400 1508 1508
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 3035 3001 3175 3141 3306
2.2 Axle load, w. load, front / rear kg 4004 / 631 4043 / 558 4336 / 638 4367 / 574 4676 / 630
2.3 Axle load, w.o. load, front / rear kg 1380 / 1655 1493 / 1508 1385 / 1790 1499 / 1642 1489 / 1817
Wheels / chassis
3.1 Tyres SE(L) / SE(L) SE(L) / SE(L) SE / SE SE / SE SE / SE
3.2 Tyre size, at front mm 18 x 7-8 18 x 7-8 200 / 50-10 200 / 50-10 200 / 50-10
3.3 Tyre size, at rear mm 16 x 6-8
3.5 Wheels, number front/rear (× = driven wheels) 2x/2
3.6 Track width, front b
10
mm 904 904 914 914 914
3.7 Track width, rear b
11
mm 830
Basic dimensions
4.1 Tilt of mast/fork carriage forward/backward α/ β ° 7/7
4.2 Mast height (lowered) h
1
mm 2000
4.2.1 Total height h15 mm
4.3 Free lift h
2
mm 150
4.4 Lift h
3
mm 3000
4.5 Extended mast height h
4
mm 3560 3560 3587 3587 3587
4.7 Height of overhead guard h
6
mm 2040
4.8 Seat height/stand height h
7
mm 920
4.12 Coupling height h
10
mm 410
4.12.1 2nd coupling height mm 580
4.19 Overall length l
1
mm 3140 3248 3140 3248 3248
4.20 Length incl. back of forks l
2
mm 1990 2098 1990 2098 2098
4.21 Total width b
1
/b
2
mm 1060 1060 1120 1120 1120
4.22 Fork dimensions s/e/l mm 40 / 100 / 1150
4.23 Fork carriage ISO 2328, class/type A, B 2A
4.24 Fork carriage width b
3
mm 980
4.31 Floor clearance with load under mast m
1
mm 80
4.32 Floor clearance centre wheelbase m
2
mm 100
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 3403 3526 3403 3526 3526
4.33.5 working aisle width for 800 x 1200 pallet (lengthways) Ast mm 3599 3725 3599 3725 3725
4.35 Turning radius W
a
mm 1859 1985 1859 1985 1985
4.36 Smallest pivot point distance b
13
mm 498 562 498 562 562
Performance da
ta
5.1 Travel speed, w. / w.o. load km/h 17 / 17
5.2 Lift speed, w. / w.o. load m/s 0.49 / 0.6 0.49 / 0.6 0.44 / 0.55 0.44 / 0.55 0.4 / 0.55
5.3 Lower speed, w. / w.o. load m/s 0.55 / 0.55
5.5 Drawbar pull w. / w.o. load N 2150 / 2450 2100 / 2450 2000 / 2300 2000 / 2300 1900 / 2300
5.6 Max. drawbar pull, laden/unladen N
12700 /
12700
12700 /
12700
12400 /
12200
12400 /
12200
12300 /
12000
5.7 Gradeability laden/unladen % 12 / 20
5.8 Max. gradeability, laden/unladen % 27 / 35 27 / 35 26 / 35 25 / 35 24 / 35
5.9 Acceleration time w. / w.o. load S 3.8 / 3.4 3.8 / 3.4 3.9 / 3.5 3.9 / 3.5 4 / 3.5
5.10 Service brake electric/mechanical
Electrics
6.1 Drive motor rating S2 60 min. kW 4.5 / 4,5
6.2 Lift motor rating at S3 15% kW 11.5
6.3 Battery according to DIN 43531/35/36 A,B,C, no A 43531
6.4 Battery voltage/nominal capacity K5 V/Ah 48 / 625 48 / 750 48 / 625 48 / 750 48 / 750
6.5 Battery weight kg 855 1025 855 1025 1025
Battery dimensions L/W/H mm
830 / 630
/ 627
830 / 738
/ 627
830 / 630
/ 627
830 / 738
/ 627
830 / 738
/ 627
6.6 Energy consumption according to VDI cycle kWh/h 4.3 2) 4.5 2) 4.8 2) 4.8 2) 5 2)
Misc.
8.1 Type of drive control Impuls/AC
8.2 working pressure for attachments bar 200
8.3 oil flow for attachments l/min 25
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 67
8.5 Trailer coupling, model/type DIN DIN 15170/H
