EFG 213/215/216k/216/218k/218/220
a
2
a
2
e
Ast
R
Wa
b
l
6
b
12
m
1 m
2
s
Q
l
2
l
l 1
x y
h 2
h 10
h
7
h
6
c
h
1
h
3
h
4
Capacity
EFG 213
EFG 215
EFG 216k/216
EFG 218k/218
EFG 220
200 300 400 500 600 700
1800
kg 2000
1600
1400
1200
1000
800
Load centre distance “c” in mm
Standard mast types EFG 213/215/216k/216/218k/218/220 Capacity chart (kg)
Lift
h
3
Lowered
mast
height
h
1
Free lift
h
2
Extended mast
height
h
4
Mast tilt forward /
back
α/ β
c=500
no side-shift, tyres are simply solid
(mm) (mm) (mm) (mm) (°)
EFG 213 /
215 / 216k
/ 216
EFG 218k
/ 218 /
220
EFG 213 /
215 / 216k
/ 216
EFG 218k
/ 218 /
220
EFG 213 /
215 / 216k
/ 216
EFG 218k
/ 218 /
220
EFG 213 EFG 215 EFG 216k
/ 216
EFG 218k
/ 218
EFG 220
Duplex ZT 3000 2000 150 150 3550 3585 7/7 7/7 1300 1500 1600 1800 2000
3100 2050 150 150 3650 3685 7/7 7/7 1300 1500 1600 1800 2000
3300 2150 150 150 3850 3885 7/7 7/7 1300 1500 1600 1800 2000
3600 2300 150 150 4150 4185 7/7 7/7 1300 1500 1600 1800 2000
4000 2500 150 150 4550 4585 7/3 7/7 1300 1500 1600 1800 2000
4500 2800 150 150 5050 5085 7/7 7/7 1300 1500 1600 1800 2000
5000 3050 150 150 5550 5585 7/5 7/5 1200 1400 1500 1700 1850
Duplex ZZ 3000 1955 1405 1340 3550 3615 7/7 7/7 1300 1500 1600 1800 2000
3100 2005 1455 1390 3650 3715 7/7 7/5 1300 1500 1600 1800 2000
3300 2105 1555 1490 3850 3915 7/7 7/7 1300 1500 1600 1800 2000
3600 2255 1705 1640 4150 4215 7/7 7/7 1300 1500 1600 1800 2000
4000 2455 1905 1840 4550 4615 7/7 7/7 1300 1500 1600 1800 2000
Triplex DZ 4350 1955 1395 1338 4910 4967 7/7 7/5 1300 1500 1600 1800 2000
4500 2005 1455 1390 5050 5115 7/7 7/7 1300 1450 1600 1800 2000
4800 2105 1555 1490 5350 5415 7/5 7/5 1250 1400 1550 1700 1900
5000 2180 1630 1565 5550 5615 7/5 7/5 1200 1350 1500 1650 1800
5500 2355 1805 1740 6050 6115 7/5 7/5 1050 1250 1350 1500 1600
6000 2555 2005 1940 6550 6615 7/5 7/5 900 1500 1150 1300 1400
6500 2805 2255 2190 7050 7115 7/5 7/5 750 1500 950 1100 1150
