1) 11.0 / 11.0 km/h in the fork direction
2) different battery sizes change these values
3) mast-dependent
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 04/2008
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model ETV C16 ETV C20
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation transverse seat
1.5 Load capacity/rated load Q t 1.6 2
1.6 Load centre distance c mm 600
1.8 Load distance x mm 400 2) 421 2)
1.8.1 Load distance, mast reached forward x
1
mm 290
1.9 Wheelbase y mm 1460 1520
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 3640 4010
2.3 Axle load, w.o. load, front / rear kg 2230 / 1410 2410 / 1600
2.4 Axle loading forks forward with load at front / rear kg 670 / 4570 510 / 5500
2.5 Axle loading forks retracted with load at front / rear kg 1965 / 3275 2146 / 3864
Wheels /
chassis
3.1 Tyres SE
3.2 Tyre size, at front mm 200/50 -10
3.3 Tyre size, at rear mm 180/60 -10
3.5 Wheels, number front/rear (× = driven wheels) 1x / 2
3.7 Track width, rear b
11
mm 1210 1240
Basic dimensions
4.1 Tilt of mast/fork carriage forward/backward α/ β ° 2/4 3)
4.2 Mast height (lowered) h
1
mm 2300 2400
4.2.1 Total height h15 mm
4.3 Free lift h
2
mm 1656 1670
4.4 Lift h
3
mm 5300
4.5 Extended mast height h
4
mm 5944 6046
4.7 Height of overhead guard h
6
mm 2250
4.8 Seat height/stand height h
7
mm 1157
4.10 height of support arms h8 mm 464
4.19 Overall length l
1
mm 2484 2) 2524 2)
4.20 Length incl. back of forks l
2
mm 1334 2) 1374 2)
4.21 Total width b
1
/b
2
mm 1370 / 1270 1400 / 1270
4.22 Fork dimensions s/e/l mm 40 / 120 / 1150 50 / 140 / 1150
4.23 Fork carriage ISO 2328, class/type A, B 2B
4.24 Fork carriage width b
3
mm 800
4.25 Width over forks b
5
mm 356 / 692 356 / 712
4.26 Width between support arms/loading surfaces b
4
mm 940
4.28 mast reach l
4
mm 690 2) 711 2)
4.31 Floor clearance with load under mast m
1
mm 90
4.32 Floor clearance centre wheelbase m
2
mm 80
4.32.1 Ground clearance at lowest point mm 55
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 2784 2) 2829 2)
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2829 2) 2871 2)
truck diagonal mm 2205 2255
4.35 Turning radius W
a
mm 1735 1795
4.37 length over the support arms l
7
mm 1986 2046
Performance da
ta
5.1 Travel speed, w. / w.o. load km/h 11.8 / 12.2 1)
5.2 Lift speed, w. / w.o. load m/s 0.4 / 0.7 0.32 / 0.6
5.3 Lower speed, w. / w.o. load m/s 0.5 / 0.5
5.4 Traverse speed w. / w.o. load m/s 0.2 / 0.2 0.15 / 0.15
5.7 Gradeability laden/unladen % 7 / 10 6 / 10
5.8 Max. gradeability, laden/unladen % 10 / 15
5.9 Acceleration time w. / w.o. load S 5.2 / 4.8 5.4 / 4.6
5.10 Service brake electric
Electrics
6.1 Drive motor rating S2 60 min. kW 6.9
6.2 Lift motor rating at S3 15% kW 10.0
6.3 Battery according to DIN 43531/35/36 A,B,C, no DIN 43531 - C
6.4 Battery voltage/nominal capacity K5 V/Ah 48 / 560
6.5 Battery weight kg 937
Misc.
8.1 Type of drive control Mosfet control AC
8.2 working pressure for attachments bar 150
8.3 oil flow for attachments l/min 20
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 70
