1)
337 mm for DZ mast; for integral sideshift: x = 362 mm (DZ mast 369 mm); for sideshift attachment: x = 390 mm (DZ mast 397 mm)
2)
45 VDI work cycles/h
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 09/2011
Identifica
tion
1.1
Manufacturer (short form)
Jungheinrich
1.2
Model
EFG 110
EFG 110k
EFG 113
EFG 115
1.3
Drive
Electrics
1.4
Manual, pedestrian, stand-on, seated, order picker operation
seat
1.5
Load capacity/rated load
Q t
1
1
1.25
1.5
1.6
Load centre distance
c mm
500
1.8
Load distance
x mm
330
1)
1.9
Wheelbase
y mm
1038
984
1146
1200
W
eights
2.1.1
Net weight incl. battery (see row 6.5)
kg
2570
2490
2760
2870
2.2
Axle load, w. load, front / rear
kg
2945 / 625
2940 / 550
3390 / 620
3805 / 565
2.3
Axle load, w.o. load, front / rear
kg
1145 / 1425
1095 / 1395
1235 / 1525
1270 / 1600
Wheels / chassis
3.1
Tyres
SE
3.2
Tyre size, at front
mm
18 x 7-8
3.3
Tyre size, at rear
mm
18 x 7-8
3.5
Wheels, number front/rear (× = driven wheels)
2/1x
3.6
Track width, front
b
10
mm
838
3.7
Track width, rear
b
11
mm
0
Basic dimensions
4.1
Tilt of mast/fork carriage forward/backward
α/
β °
5/6
4.2
Mast height (lowered)
h
1
mm
2000
4.2.1
Total height
h15 mm
4.3
Free lift
h
2
mm
150
4.4
Lift
h
3
mm
3000
4.5
Extended mast height
h
4
mm
3550
4.7
Height of overhead guard
h
6
mm
2090
4.8
Seat height/stand height
h
7
mm
900
4.12
Coupling height
h
10
mm
635
4.19
Overall length
l
1
mm
2773
2719
2881
2935
4.20
Length incl. back of forks
l
2
mm
1623
1569
1731
1785
4.21
Total width
b
1
/b
2
mm
990
4.22
Fork dimensions
s/e/l mm
35 / 100 / 1150
4.23
Fork carriage ISO 2328, class/type A, B
2A
4.24
Fork carriage width
b
3
mm
950
4.31
Floor clearance with load under mast
m
1
mm
90
4.32
Floor clearance centre wheelbase
m
2
mm
100
4.33
Aisle width for pallets 1000 × 1200 sideways
Ast mm
2952
2898
3060
3114
4.34
Aisle width for pallets 800 × 1200 lengthways
Ast mm
3074
3020
3182
3236
4.35
Turning radius
W
a
mm
1293
1239
1401
1455
4.36
Smallest pivot point distance
b
13
mm
0
Performance da
ta
5.1
Travel speed, w. / w.o. load
km/h
12 / 12.5
5.2
Lift speed, w. / w.o. load
m/s
0.29 / 0.5
0.28 / 0.5
0.25 / 0.5
0.24 / 0.5
5.3
Lower speed, w. / w.o. load
m/s
0.58 / 0.6
5.5
Drawbar pull w. / w.o. load
N
1150 / 1250
1150 / 1250
1100 / 1250
1055 / 1250
5.6
Max. drawbar pull, laden/unladen
N
4400 / 4500
4400 / 4500
4375 / 4500
4350 / 4500
5.7
Gradeability laden/unladen
%
8 / 11.5
8.5 / 12
7 / 11
6.5 / 10.5
5.8
Max. gradeability, laden/unladen
%
12.5 / 17.5
13 / 18
11 / 16.5
10 / 16
5.9.1
Acceleration time w / w.o. load (to 10 m)
S
5.1 / 4.6
5.1 / 4.6
5.4 / 4.7
5.6 / 4.8
5.10
Service brake
hydraulic
Electrics
6.1
Drive motor rating S2 60 min.
kW
4.0
6.2
Lift motor rating at S3 15%
kW
6.0
6.3
Battery according to DIN 43531/35/36 A,B,C, no
A 43535
6.4
Battery voltage/nominal capacity K5
V/Ah
24 / 625
24 / 500
24 / 875
24 / 1000
6.5
Battery weight
kg
450
380
600
690
Battery dimensions L/W/H
mm
830 / 327 /
627
830 / 273 /
627
830 / 435 /
627
830 / 489 /
627
6.6
Energy consumption according to VDI cycle
kWh/h
3.6
2)
3.6
2)
3.9
2)
4.1
2)
Misc.
8.1
Type of drive control
Impuls/AC
8.2
working pressure for attachments
bar
160
160
185
210
8.3
oil flow for attachments
l/min
14
8.4
Sound pressure level at operator’s ear according to EN 12053
dB (A)
63
8.5
Trailer coupling, model/type DIN
DIN 15170-H
