1) different battery sizes change these values
2) mast-dependent
3) Maximum battery size 775 Ah
4) With Drive & Lift Plus options package
5) With Drive Plus options package
6) With Lift Plus options package
7) With load wheel cover: + 30 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may result in different values.
Technical data in line with VDI 2198
as at: 11/2013
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model ETV 318 ETV 320 ETM 325 ETV 325
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation transverse seat
1.5 Load capacity/rated load Q t 1.8 2 2.5 2.5
1.6 Load centre distance c mm 600
1.8 Load distance x mm 364 1) 412 1) 389 1) 487 1)
1.8.1 Load distance, mast reached forward x
1
mm 205 230 230 230
1.9 Wheelbase y mm 1460 1518 1673 1673
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 3522 3650 3895 3700
2.3 Axle load, w.o. load, front / rear kg 2074 / 1448 1842 / 1228 2274 / 1621 2264 / 1436
2.4 Axle loading forks forward with load at front / rear kg 446 / 4876 560 / 4110 366 / 6029 602 / 5598
2.5 Axle loading forks retracted with load at front / rear kg 1805 / 3517 1681 / 2989 2057 / 4338 2032 / 4168
Wheels /
chassis
3.1 Tyres Vulkollan ®
3.2 Tyre size, at front mm Ø 343 x 114 Ø 343 x 114 Ø 343 x 140 Ø 343 x 140
3.3 Tyre size, at rear mm Ø 285 x 100 Ø 355 x 106 Ø 355 x 135 Ø 355 x 135
3.5 Wheels, number front/rear (× = driven wheels) 1x / 2
3.7 Track width, rear b
11
mm 1136 1155 1034 1184
Basic dimensions
4.1 Tilt of mast/fork carriage forward/backward α/ β ° 1/5 2)
4.2 Mast height (lowered) h
1
mm 2400
4.3 Free lift h
2
mm 1670
4.4 Lift h
3
mm 5300
4.5 Extended mast height h
4
mm 6046
4.7 Height of overhead guard h
6
mm 2190
4.8 Seat height/stand height h
7
mm 1057
4.10 height of support arms h8 mm 285 7) 355 7) 355 7) 355 7)
4.19 Overall length l
1
mm 2418 2459 2547 2547
4.20 Length incl. back of forks l
2
mm 1306 1) 1316 1) 1494 1) 1396 1)
4.21 Total width b
1
/b
2
mm 1270 / 1270 1290 / 1270 1198 / 1120 1348 / 1270
4.22 Fork dimensions s/e/l mm 40 / 120 / 1150 50 / 140 / 1150 50 / 140 / 1150 50 / 140 / 1150
4.23 Fork carriage ISO 2328, class/type A, B 2B
4.24 Fork carriage width b
3
mm 830
4.25 Width over forks b
5
mm 335 / 730 356 / 750 356 / 580 356 / 750
4.26 Width between support arms/loading surfaces b
4
mm 940 940 790 940
4.28 mast reach l
4
mm 569 1) 624 1) 703 1) 736 1)
4.32 Floor clearance centre wheelbase m
2
mm 80 95 95 95
4.32.1 Ground clearance at lowest point mm 30
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 2737 1) 2750 1) 2921 1) 2854 1)
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2790 1) 2794 1) 2969 1) 2883 1)
4.35 Turning radius W
a
mm 1663 1710 1865 1865
4.37 length over the support arms l
7
mm 1842 1920 2075 2075
Performance da
ta
5.1 Travel speed, w. / w.o. load km/h 14 / 14 5) 14 / 14 5) 14 / 14 14 / 14
5.2 Lift speed, w. / w.o. load m/s 0.38 / 0.64 6) 0.38 / 0.64 6) 0.35 / 0.64 0.35 / 0.64
5.3 Lower speed, w. / w.o. load m/s 0.55 / 0.55
5.4 Traverse speed w. / w.o. load m/s 0.2 / 0.2 6) 0.2 / 0.2 6) 0.2 / 0.2 0.2 / 0.2
5.7 Gradeability laden/unladen % 7 / 11
5.8 Max. gradeability, laden/unladen % 9 / 13 10 / 15 10 / 15 10 / 15
5.9 Acceleration time w. / w.o. load S 4.6 / 4.2 5) 4.6 / 4.2 5) 5.4 / 4.8 5.4 / 4.8
5.10 Service brake electric
Electrics
6.1 Drive motor rating S2 60 min. kW 6.9 5) 6.9 5) 6.9 6.9
6.2 Lift motor rating at S3 15% kW 14.0 6) 14.0 6) 14.0 14.0
6.3 Battery according to DIN 43531/35/36 A,B,C, no DIN 43531 - C DIN 43531 - C DIN 43531 - B DIN 43531 - C
6.4 Battery voltage/nominal capacity K5 V/Ah 48 / 620 3) 48 / 620 48 / 775 48 / 620
6.5 Battery weight kg 1005 1005 1210 1005
6.6 Energy consumption according to VDI cycle kWh/h 4.3 4) 4.5 4) 4.9 4.9
6.7 Throughput efficiency t/h 72.8 4) 85.4 4) 99.2 99.2
6.8 Energy consumption at max. throughput kWh/h 4.1 4) 4.15 4) 4.3 4.3
Misc.
8.1 Type of drive control Mosfet / AC
8.2 working pressure for attachments bar 150
8.3 oil flow for attachments l/min 20
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 68
